The International A26 engine continues to power Class 8 trucks with a strong balance of performance and fuel efficiency. For 2024 and 2025 models, technicians can benefit from staying current with the most up-to-date fault code information.
International A26 (2024–2025) Engine Overview
- Displacement: 12.4L
- Configuration: Inline 6-Cylinder
- Horsepower Range: 370–515 HP
- Torque: Up to 1,850 lb-ft
- Emissions System: SCR with DPF
- Applications: International LT, RH Series, vocational and regional haul trucks
📍 Get FREE Fault Code Information for all makes and models in Diesel Repair
Fault Codes for International A26 (2024–2025)
| Fault | PID | SPN | FMI | SID | Title |
| SPN 100 FMI 14 | 100 | 14 | Engine Oil Pressure 1: Special Instructions | ||
| SPN 100 FMI 17 | 100 | 17 | Engine Oil Pressure 1: Data Valid But Below Normal Operating Range – Least Severe Level | ||
| SPN 100 FMI 3 | 100 | 3 | Engine Oil Pressure 1: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 100 FMI 4 | 100 | 4 | Engine Oil Pressure 1: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 102 FMI 0 | 102 | Engine Intake Manifold #1 Pressure: Data Valid But Above Normal Operational Range – Most Severe Level | |||
| SPN 102 FMI 1 | 102 | 1 | Engine Intake Manifold #1 Pressure: Data Valid But Below Normal Operational Range – Most Severe Level | ||
| SPN 102 FMI 10 | 102 | 10 | Engine Intake Manifold #1 Pressure : Abnormal Rate Of Change | ||
| SPN 102 FMI 16 | 102 | 16 | Engine Intake Manifold #1 Pressure: Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 102 FMI 18 | 102 | 18 | Engine Intake Manifold #1 Pressure : Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 102 FMI 2 | 102 | 2 | Engine Intake Manifold #1 Pressure: Data Erratic, Intermittent Or Incorrect | ||
| SPN 102 FMI 3 | 102 | 3 | Engine Intake Manifold #1 Pressure: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 102 FMI 31 | 102 | 31 | Engine Intake Manifold #1 Pressure : Condition Exists | ||
| SPN 102 FMI 4 | 102 | 4 | Engine Intake Manifold #1 Pressure: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 105 FMI 0 | 105 | Engine Intake Manifold 1 Temperature: Data Valid But Above Normal Operational Range – Most Severe Level | |||
| SPN 105 FMI 10 | 105 | 10 | Engine Intake Manifold 1 Temperature : Abnormal Rate Of Change | ||
| SPN 105 FMI 18 | 105 | 18 | Engine Intake Manifold 1 Temperature : Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 105 FMI 2 | 105 | 2 | Engine Intake Manifold 1 Temperature: Data Erratic, Intermittent Or Incorrect | ||
| SPN 105 FMI 3 | 105 | 3 | Engine Intake Manifold 1 Temperature: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 105 FMI 4 | 105 | 4 | Engine Intake Manifold 1 Temperature: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 1072 FMI 3 | 1072 | 3 | Engine Compression Brake Output #1: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 1072 FMI 4 | 1072 | 4 | Engine Compression Brake Output #1: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 1072 FMI 5 | 1072 | 5 | Engine Compression Brake Output #1: Current Below Normal Or Open Circuit | ||
| SPN 1073 FMI 3 | 1073 | 3 | Engine Compression Brake Output #2: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 1073 FMI 4 | 1073 | 4 | Engine Compression Brake Output #2: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 1073 FMI 5 | 1073 | 5 | Engine Compression Brake Output #2: Current Below Normal Or Open Circuit | ||
| SPN 108 FMI 1 | 108 | 1 | Barometric Pressure: Data Valid But Below Normal Operational Range – Most Severe Level | ||
| SPN 108 FMI 2 | 108 | 2 | Barometric Pressure: Data Erratic, Intermittent Or Incorrect | ||
| SPN 108 FMI 3 | 108 | 3 | Barometric Pressure: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 108 FMI 4 | 108 | 4 | Barometric Pressure : Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 109 FMI 0 | 109 | Engine Coolant Pressure 1: Data Valid But Above Normal Operational Range – Most Severe Level | |||
| SPN 109 FMI 1 | 109 | 1 | Engine Coolant Pressure 1: Data Valid But Below Normal Operational Range – Most Severe Level | ||
| SPN 109 FMI 20 | 109 | 20 | Engine Coolant Pressure 1: Data Drifted High | ||
| SPN 109 FMI 21 | 109 | 21 | Engine Coolant Pressure 1: Data Drifted Low | ||
| SPN 109 FMI 3 | 109 | 3 | Engine Coolant Pressure 1: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 109 FMI 4 | 109 | 4 | Engine Coolant Pressure 1: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 110 FMI 0 | 110 | Engine Coolant Temperature: Data Valid But Above Normal Operational Range – Most Severe Level | |||
| SPN 110 FMI 10 | 110 | 10 | Engine Coolant Temperature: Abnormal Rate Of Change | ||
| SPN 110 FMI 14 | 110 | 14 | Engine Coolant Temperature : Special Instructions | ||
| SPN 110 FMI 15 | 110 | 15 | Engine Coolant Temperature: Data Valid But Above Normal Operating Range – Least Severe Level | ||
| SPN 110 FMI 16 | 110 | 16 | Engine Coolant Temperature: Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 110 FMI 18 | 110 | 18 | Engine Coolant Temperature: Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 110 FMI 2 | 110 | 2 | Engine Coolant Temperature: Data Erratic, Intermittent or Incorrect | ||
| SPN 110 FMI 3 | 110 | 3 | Engine Coolant Temperature : Voltage Above Normal, Or Shorted To High Source | ||
| SPN 110 FMI 4 | 110 | 4 | Engine Coolant Temperature : Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 1110 FMI 31 | 1110 | 31 | Engine Protection System Has Shutdown Engine: Condition Exists | ||
| SPN 111 FMI 1 | 111 | 1 | Engine Coolant Level 1: Data Valid But Below Normal Operational Range – Most Severe Level | ||
| SPN 111 FMI 3 | 111 | 3 | Engine Coolant Level 1: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 111 FMI 4 | 111 | 4 | Engine Coolant Level 1: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 1136 FMI 16 | 1136 | 16 | Engine ECU Temperature: Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 1136 FMI 18 | 1136 | 18 | Engine ECU Temperature: Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 1136 FMI 3 | 1136 | 3 | Engine ECU Temperature: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 1136 FMI 4 | 1136 | 4 | Engine ECU Temperature: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 1136 FMI 7 | 1136 | 7 | Engine ECU Temperature: Mechanical System Not Responding Or Out Of Adjustment | ||
| SPN 1209 FMI 0 | 1209 | Engine Exhaust Pressure 1 : Data Valid But Above Normal Operational Range – Most Severe Level | |||
| SPN 1209 FMI 1 | 1209 | 1 | Engine Exhaust Pressure 1: Data Valid But Below Normal Operational Range – Most Severe Level | ||
| SPN 1209 FMI 2 | 1209 | 2 | Engine Exhaust Pressure 1: Data Erratic, Intermittent Or Incorrect | ||
| SPN 1209 FMI 3 | 1209 | 3 | Engine Exhaust Pressure 1: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 1209 FMI 31 | 1209 | 31 | Engine Exhaust Pressure 1 : Condition Exists | ||
| SPN 1209 FMI 4 | 1209 | 4 | Engine Exhaust Pressure 1: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 1244 FMI 3 | 1244 | 3 | Engine Fuel Actuator 2 Control Command: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 1244 FMI 4 | 1244 | 4 | Engine Fuel Actuator 2 Control Command: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 1244 FMI 5 | 1244 | 5 | Engine Fuel Actuator 2 Control Command: Current Below Normal Or Open Circuit | ||
| SPN 1244 FMI 7 | 1244 | 7 | Engine Fuel Actuator 2 Control Command: Mechanical System Not Responding Or Out Of Adjustment | ||
| SPN 1322 FMI 31 | 1322 | 31 | Engine Misfire for Multiple Cylinders: Condition Exists | ||
| SPN 1323 FMI 31 | 1323 | 31 | Engine Cylinder 1 Misfire Rate: Condition Exists | ||
| SPN 1324 FMI 31 | 1324 | 31 | Engine Cylinder 2 Misfire Rate: Condition Exists | ||
| SPN 1325 FMI 31 | 1325 | 31 | Engine Cylinder 3 Misfire Rate: Condition Exists | ||
| SPN 1326 FMI 31 | 1326 | 31 | Engine Cylinder 4 Misfire Rate: Condition Exists | ||
| SPN 1327 FMI 31 | 1327 | 31 | Engine Cylinder 5 Misfire Rate: Condition Exists | ||
| SPN 1328 FMI 31 | 1328 | 31 | Engine Cylinder 6 Misfire Rate: Condition Exists | ||
| SPN 132 FMI 0 | 132 | Engine Intake Air Mass Flow Rate: Data Valid But Above Normal Operational Range – Most Severe Level | |||
| SPN 132 FMI 13 | 132 | 13 | Engine Intake Air Mass Flow Rate: Out Of Calibration | ||
| SPN 132 FMI 14 | 132 | 14 | Engine Intake Air Mass Flow Rate : Special Instructions | ||
| SPN 132 FMI 16 | 132 | 16 | Engine Intake Air Mass Flow Rate : Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 132 FMI 18 | 132 | 18 | Engine Intake Air Mass Flow Rate : Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 132 FMI 3 | 132 | 3 | Engine Intake Air Mass Flow Rate: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 132 FMI 4 | 132 | 4 | Engine Intake Air Mass Flow Rate: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 1378 FMI 31 | 1378 | 31 | Engine Oil Change Interval: Condition Exists | ||
| SPN 1413 FMI 14 | 1413 | 14 | Engine Cylinder 1 Ignition Timing : Special Instructions | ||
| SPN 1413 FMI 31 | 1413 | 31 | Engine Cylinder 1 Ignition Timing : Condition Exists | ||
| SPN 1414 FMI 14 | 1414 | 14 | Engine Cylinder 2 Ignition Timing : Special Instructions | ||
| SPN 1414 FMI 31 | 1414 | 31 | Engine Cylinder 2 Ignition Timing : Condition Exists | ||
| SPN 1415 FMI 14 | 1415 | 14 | Engine Cylinder 3 Ignition Timing : Special Instructions | ||
| SPN 1415 FMI 31 | 1415 | 31 | Engine Cylinder 3 Ignition Timing : Condition Exists | ||
| SPN 1416 FMI 14 | 1416 | 14 | Engine Cylinder 4 Ignition Timing : Special Instructions | ||
| SPN 1416 FMI 31 | 1416 | 31 | Engine Cylinder 4 Ignition Timing : Condition Exists | ||
| SPN 1417 FMI 14 | 1417 | 14 | Engine Cylinder 5 Ignition Timing : Special Instructions | ||
| SPN 1417 FMI 31 | 1417 | 31 | Engine Cylinder 5 Ignition Timing : Condition Exists | ||
| SPN 1418 FMI 14 | 1418 | 14 | Engine Cylinder 6 Ignition Timing : Special Instructions | ||
| SPN 1418 FMI 31 | 1418 | 31 | Engine Cylinder 6 Ignition Timing : Condition Exists | ||
| SPN 1569 FMI 0 | 1569 | Engine Protection Torque Derate: Data Valid But Above Normal Operational Range – Most Severe Level | |||
| SPN 1569 FMI 15 | 1569 | 15 | Engine Protection Torque Derate: Data Valid But Above Normal Operating Range – Least Severe Level | ||
| SPN 1569 FMI 16 | 1569 | 16 | Engine Protection Torque Derate: Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 157 FMI 0 | 157 | Engine Fuel 1 Injector Metering Rail 1 Pressure: Data Valid But Above Normal Operational Range – Most Severe Level | |||
| SPN 157 FMI 1 | 157 | 1 | Engine Fuel 1 Injector Metering Rail 1 Pressure: Data Valid But Below Normal Operational Range – Most Severe Level | ||
| SPN 157 FMI 10 | 157 | 10 | Engine Fuel 1 Injector Metering Rail 1 Pressure: Abnormal Rate Of Change | ||
| SPN 157 FMI 11 | 157 | 11 | Engine Fuel 1 Injector Metering Rail 1 Pressure : Root Cause Not Known | ||
| SPN 157 FMI 14 | 157 | 14 | Engine Fuel 1 Injector Metering Rail 1 Pressure: Special Instructions | ||
| SPN 157 FMI 16 | 157 | 16 | Engine Fuel 1 Injector Metering Rail 1 Pressure: Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 157 FMI 18 | 157 | 18 | Engine Fuel 1 Injector Metering Rail 1 Pressure: Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 157 FMI 2 | 157 | 2 | Engine Fuel 1 Injector Metering Rail 1 Pressure: Data Erratic, Intermittent Or Incorrect | ||
| SPN 157 FMI 20 | 157 | 20 | Engine Fuel 1 Injector Metering Rail 1 Pressure: Data Drifted High | ||
| SPN 157 FMI 21 | 157 | 21 | Engine Fuel 1 Injector Metering Rail 1 Pressure: Data Drifted Low | ||
| SPN 157 FMI 31 | 157 | 31 | Engine Fuel 1 Injector Metering Rail 1 Pressure: Condition Exists | ||
| SPN 157 FMI 7 | 157 | 7 | Engine Fuel 1 Injector Metering Rail 1 Pressure: Mechanical System Not Responding Or Out Of Adjustment | ||
| SPN 158 FMI 16 | 158 | 16 | Key Switch Battery Potential: Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 158 FMI 18 | 158 | 18 | Key Switch Battery Potential: Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 158 FMI 3 | 158 | 3 | Key Switch Battery Potential: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 158 FMI 4 | 158 | 4 | Key Switch Battery Potential: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 1659 FMI 14 | 1659 | 14 | Engine Coolant System Thermostat 1: Special Instructions | ||
| SPN 1659 FMI 18 | 1659 | 18 | Engine Coolant System Thermostat 1: Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 171 FMI 0 | 171 | Ambient Air Temperature: Data Valid But Above Normal Operational Range – Most Severe Level | |||
| SPN 171 FMI 2 | 171 | 2 | Ambient Air Temperature: Data Erratic, Intermittent Or Incorrect | ||
| SPN 171 FMI 3 | 171 | 3 | Ambient Air Temperature : Voltage Above Normal, Or Shorted To High Source | ||
| SPN 171 FMI 4 | 171 | 4 | Ambient Air Temperature: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 172 FMI 0 | 172 | Engine Intake 1 Air Temperature: Data Valid But Above Normal Operational Range – Most Severe Level | |||
| SPN 172 FMI 2 | 172 | 2 | Engine Intake 1 Air Temperature: Data Erratic, Intermittent Or Incorrect | ||
| SPN 172 FMI 3 | 172 | 3 | Engine Intake 1 Air Temperature: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 172 FMI 4 | 172 | 4 | Engine Intake 1 Air Temperature: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 173 FMI 2 | 173 | 2 | Engine Exhaust Temperature: Data Erratic, Intermittent Or Incorrect | ||
| SPN 173 FMI 3 | 173 | 3 | Engine Exhaust Temperature: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 173 FMI 4 | 173 | 4 | Engine Exhaust Temperature: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 174 FMI 0 | 174 | Engine Fuel 1 Temperature 1: Data Valid But Above Normal Operational Range – Most Severe Level | |||
| SPN 174 FMI 2 | 174 | 2 | Engine Fuel 1 Temperature 1: Data Erratic, Intermittent Or Incorrect | ||
| SPN 174 FMI 3 | 174 | 3 | Engine Fuel 1 Temperature 1: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 174 FMI 4 | 174 | 4 | Engine Fuel 1 Temperature 1: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 175 FMI 14 | 175 | 14 | Engine Oil Temperature 1: Special Instructions | ||
| SPN 175 FMI 15 | 175 | 15 | Engine Oil Temperature 1: Data Valid But Above Normal Operating Range – Least Severe Level | ||
| SPN 175 FMI 2 | 175 | 2 | Engine Oil Temperature 1: Data Erratic, Intermittent Or Incorrect | ||
| SPN 175 FMI 3 | 175 | 3 | Engine Oil Temperature 1: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 175 FMI 4 | 175 | 4 | Engine Oil Temperature 1: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 1761 FMI 1 | 1761 | 1 | Aftertreatment 1 Diesel Exhaust Fluid Tank Volume: Data Valid But Below Normal Operational Range – Most Severe Level | ||
| SPN 1761 FMI 10 | 1761 | 10 | Aftertreatment 1 Diesel Exhaust Fluid Tank Volume: Abnormal Rate Of Change | ||
| SPN 1761 FMI 12 | 1761 | 12 | Aftertreatment 1 Diesel Exhaust Fluid Tank Volume: Bad Intelligent Device Or Component | ||
| SPN 1761 FMI 13 | 1761 | 13 | Aftertreatment 1 Diesel Exhaust Fluid Tank Volume: Out Of Calibration | ||
| SPN 1761 FMI 17 | 1761 | 17 | Aftertreatment 1 Diesel Exhaust Fluid Tank Volume: Data Valid But Below Normal Operating Range – Least Severe Level | ||
| SPN 1761 FMI 18 | 1761 | 18 | Aftertreatment 1 Diesel Exhaust Fluid Tank Volume: Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 1761 FMI 3 | 1761 | 3 | Aftertreatment 1 Diesel Exhaust Fluid Tank Volume: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 1761 FMI 4 | 1761 | 4 | Aftertreatment 1 Diesel Exhaust Fluid Tank Volume: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 1761 FMI 9 | 1761 | 9 | Aftertreatment 1 Diesel Exhaust Fluid Tank Volume: Abnormal Update Rate | ||
| SPN 1868 FMI 3 | 1868 | 3 | Maintain Actuator Power: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 1868 FMI 4 | 1868 | 4 | Maintain Actuator Power: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 1868 FMI 5 | 1868 | 5 | Maintain Actuator Power: Current Below Normal Or Open Circuit | ||
| SPN 188 FMI 14 | 188 | 14 | Engine Speed At Idle, Point 1: Special Instructions | ||
| SPN 188 FMI 16 | 188 | 16 | Engine Speed At Idle, Point 1: Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 188 FMI 18 | 188 | 18 | Engine Speed At Idle, Point 1: Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 190 FMI 3 | 190 | 3 | Engine Speed : Voltage Above Normal, Or Shorted To High Source | ||
| SPN 190 FMI 4 | 190 | 4 | Engine Speed : Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 191 FMI 19 | 191 | 19 | Transmission 1 Output Shaft Speed: Received Network Data In Error | ||
| SPN 191 FMI 2 | 191 | 2 | Transmission 1 Output Shaft Speed: Data Erratic, Intermittent Or Incorrect | ||
| SPN 191 FMI 3 | 191 | 3 | Transmission 1 Output Shaft Speed: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 191 FMI 4 | 191 | 4 | Transmission 1 Output Shaft Speed: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 2550 FMI 13 | 2550 | 13 | Manufacturer Specific Information (PropA_PDU1): Out Of Calibration | ||
| SPN 2550 FMI 2 | 2550 | 2 | Manufacturer Specific Information (PropA_PDU1): Data Erratic, Intermittent Or Incorrect | ||
| SPN 2550 FMI 9 | 2550 | 9 | Manufacturer Specific Information (PropA_PDU1): Abnormal Update Rate | ||
| SPN 2599 FMI 19 | 2599 | 19 | Fire Apparatus Pump Engagement : Received Network Data In Error | ||
| SPN 2623 FMI 3 | 2623 | 3 | Accelerator Pedal #1 Channel 2 : Voltage Above Normal, Or Shorted To High Source | ||
| SPN 2623 FMI 4 | 2623 | 4 | Accelerator Pedal #1 Channel 2: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 2629 FMI 0 | 2629 | Engine Turbocharger 1 Compressor Outlet Temperature: Data Valid But Above Normal Operational Range – Most Severe Level | |||
| SPN 2629 FMI 2 | 2629 | 2 | Engine Turbocharger 1 Compressor Outlet Temperature: Data Erratic, Intermittent Or Incorrect | ||
| SPN 2629 FMI 3 | 2629 | 3 | Engine Turbocharger 1 Compressor Outlet Temperature: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 2629 FMI 4 | 2629 | 4 | Engine Turbocharger 1 Compressor Outlet Temperature: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 2630 FMI 0 | 2630 | Engine Charge Air Cooler 1 Outlet Temperature: Data Valid But Above Normal Operational Range – Most Severe Level | |||
| SPN 2630 FMI 2 | 2630 | 2 | Engine Charge Air Cooler 1 Outlet Temperature: Data Erratic, Intermittent Or Incorrect | ||
| SPN 2630 FMI 3 | 2630 | 3 | Engine Charge Air Cooler 1 Outlet Temperature: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 2630 FMI 4 | 2630 | 4 | Engine Charge Air Cooler 1 Outlet Temperature: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 2659 FMI 10 | 2659 | 10 | Engine Exhaust Gas Recirculation 1 Mass Flow Rate : Abnormal Rate Of Change | ||
| SPN 2659 FMI 16 | 2659 | 16 | Engine Exhaust Gas Recirculation 1 Mass Flow Rate : Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 2659 FMI 18 | 2659 | 18 | Engine Exhaust Gas Recirculation 1 Mass Flow Rate : Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 2791 FMI 12 | 2791 | 12 | Engine Exhaust Gas Recirculation 1 Valve 1 Control 1: Bad Intelligent Device Or Component | ||
| SPN 2791 FMI 2 | 2791 | 2 | Engine Exhaust Gas Recirculation 1 Valve 1 Control 1: Data Erratic, Intermittent Or Incorrect | ||
| SPN 2791 FMI 3 | 2791 | 3 | Engine Exhaust Gas Recirculation 1 Valve 1 Control 1: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 2791 FMI 4 | 2791 | 4 | Engine Exhaust Gas Recirculation 1 Valve 1 Control 1: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 2791 FMI 7 | 2791 | 7 | Engine Exhaust Gas Recirculation 1 Valve 1 Control 1: Mechanical System Not Responding Or Out Of Adjustment | ||
| SPN 2791 FMI 9 | 2791 | 9 | Engine Exhaust Gas Recirculation 1 Valve 1 Control 1: Abnormal Update Rate | ||
| SPN 2797 FMI 11 | 2797 | 11 | Engine Fuel 1 Injector Group 1 : Root Cause Not Known | ||
| SPN 2798 FMI 11 | 2798 | 11 | Engine Fuel 1 Injector Group 2 : Root Cause Not Known | ||
| SPN 3031 FMI 13 | 3031 | 13 | Aftertreatment 1 Diesel Exhaust Fluid Tank Temperature 1: Out Of Calibration | ||
| SPN 3031 FMI 2 | 3031 | 2 | Aftertreatment 1 Diesel Exhaust Fluid Tank Temperature 1: Data Erratic, Intermittent Or Incorrect | ||
| SPN 3031 FMI 20 | 3031 | 20 | Aftertreatment 1 Diesel Exhaust Fluid Tank Temperature 1: Data Drifted High | ||
| SPN 3031 FMI 3 | 3031 | 3 | Aftertreatment 1 Diesel Exhaust Fluid Tank Temperature 1: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 3031 FMI 4 | 3031 | 4 | Aftertreatment 1 Diesel Exhaust Fluid Tank Temperature 1: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 3052 FMI 31 | 3052 | 31 | Engine Misfire System Monitor : Condition Exists | ||
| SPN 3061 FMI 31 | 3061 | 31 | Engine Cold Start Emission Reduction Strategy System Monitor: Condition Exists | ||
| SPN 3216 FMI 10 | 3216 | 10 | Engine Exhaust 1 NOx 1: Abnormal Rate Of Change | ||
| SPN 3216 FMI 13 | 3216 | 13 | Engine Exhaust 1 NOx 1: Out Of Calibration | ||
| SPN 3216 FMI 16 | 3216 | 16 | Engine Exhaust 1 NOx 1: Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 3216 FMI 18 | 3216 | 18 | Engine Exhaust 1 NOx 1: Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 3216 FMI 20 | 3216 | 20 | Engine Exhaust 1 NOx 1 : Data Drifted High | ||
| SPN 3216 FMI 21 | 3216 | 21 | Engine Exhaust 1 NOx 1 : Data Drifted Low | ||
| SPN 3216 FMI 4 | 3216 | 4 | Aftertreatment 1 SCR Intake NOx 1: Voltage Below Normal, or Shorted to Low Source | ||
| SPN 3216 FMI 9 | 3216 | 9 | Engine Exhaust 1 NOx 1: Abnormal Update Rate | ||
| SPN 3217 FMI 2 | 3217 | 2 | Engine Exhaust 1 Percent Oxygen 1: Data Erratic, Intermittent Or Incorrect | ||
| SPN 3218 FMI 2 | 3218 | 2 | Engine Exhaust 1 Gas Sensor 1 Power In Range: Data Erratic, Intermittent Or Incorrect | ||
| SPN 3226 FMI 10 | 3226 | 10 | Aftertreatment 1 Outlet NOx 1: Abnormal Rate Of Change | ||
| SPN 3226 FMI 11 | 3226 | 11 | Aftertreatment 1 Outlet NOx 1: Root Cause Not Known | ||
| SPN 3226 FMI 13 | 3226 | 13 | Aftertreatment 1 Outlet NOx 1: Out Of Calibration | ||
| SPN 3226 FMI 16 | 3226 | 16 | Aftertreatment 1 Outlet NOx 1 – Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 3226 FMI 18 | 3226 | 18 | Aftertreatment 1 Outlet NOx 1: Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 3226 FMI 2 | 3226 | 2 | Aftertreatment 1 Outlet NOx 1: Data Erratic, Intermittent Or Incorrect | ||
| SPN 3226 FMI 4 | 3226 | 4 | Aftertreatment 1 Outlet NOx 1: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 3226 FMI 9 | 3226 | 9 | Aftertreatment 1 Outlet NOx 1: Abnormal Update Rate | ||
| SPN 3228 FMI 2 | 3228 | 2 | Aftertreatment 1 Outlet Gas Sensor 1 Power In Range: Data Erratic, Intermittent Or Incorrect | ||
| SPN 3242 FMI 0 | 3242 | Aftertreatment 1 Diesel Particulate Filter Intake Temperature: Data Valid But Above Normal Operational Range – Most Severe Level | |||
| SPN 3242 FMI 12 | 3242 | 12 | Aftertreatment 1 Diesel Particulate Filter Intake Temperature: Bad Intelligent Device Or Component | ||
| SPN 3242 FMI 15 | 3242 | 15 | Aftertreatment 1 Diesel Particulate Filter Intake Temperature: Data Valid But Above Normal Operating Range – Least Severe Level | ||
| SPN 3242 FMI 16 | 3242 | 16 | Aftertreatment 1 Diesel Particulate Filter Intake Temperature: Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 3242 FMI 18 | 3242 | 18 | Aftertreatment 1 Diesel Particulate Filter Intake Temperature: Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 3242 FMI 2 | 3242 | 2 | Aftertreatment 1 Diesel Particulate Filter Intake Temperature: Data Erratic, Intermittent Or Incorrect | ||
| SPN 3242 FMI 20 | 3242 | 20 | Aftertreatment 1 Diesel Particulate Filter Intake Temperature: Data Drifted High | ||
| SPN 3242 FMI 21 | 3242 | 21 | Aftertreatment 1 Diesel Particulate Filter Intake Temperature: Data Drifted Low | ||
| SPN 3242 FMI 3 | 3242 | 3 | Aftertreatment 1 Diesel Particulate Filter Intake Temperature: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 3242 FMI 4 | 3242 | 4 | Aftertreatment 1 Diesel Particulate Filter Intake Temperature: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 3246 FMI 0 | 3246 | Aftertreatment 1 Diesel Particulate Filter Outlet Temperature: Data Valid But Above Normal Operational Range – Most Severe Level | |||
| SPN 3246 FMI 12 | 3246 | 12 | Aftertreatment 1 Diesel Particulate Filter Outlet Temperature: Bad Intelligent Device Or Component | ||
| SPN 3246 FMI 15 | 3246 | 15 | Aftertreatment 1 Diesel Particulate Filter Outlet Temperature: Data Valid But Above Normal Operating Range – Least Severe Level | ||
| SPN 3246 FMI 16 | 3246 | 16 | Aftertreatment 1 Diesel Particulate Filter Outlet Temperature: Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 3246 FMI 18 | 3246 | 18 | Aftertreatment 1 Diesel Particulate Filter Outlet Temperature: Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 3246 FMI 2 | 3246 | 2 | Aftertreatment 1 Diesel Particulate Filter Outlet Temperature: Data Erratic, Intermittent Or Incorrect | ||
| SPN 3246 FMI 20 | 3246 | 20 | Aftertreatment 1 Diesel Particulate Filter Outlet Temperature: Data Drifted High | ||
| SPN 3246 FMI 21 | 3246 | 21 | Aftertreatment 1 Diesel Particulate Filter Outlet Temperature: Data Drifted Low | ||
| SPN 3246 FMI 3 | 3246 | 3 | Aftertreatment 1 Diesel Particulate Filter Outlet Temperature: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 3246 FMI 4 | 3246 | 4 | Aftertreatment 1 Diesel Particulate Filter Outlet Temperature: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 3251 FMI 0 | 3251 | Aftertreatment 1 Diesel Particulate Filter Differential Pressure: Data Valid But Above Normal Operational Range – Most Severe Level | |||
| SPN 3251 FMI 16 | 3251 | 16 | Aftertreatment 1 Diesel Particulate Filter Differential Pressure: Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 3251 FMI 2 | 3251 | 2 | Aftertreatment 1 Diesel Particulate Filter Differential Pressure: Data Erratic, Intermittent Or Incorrect | ||
| SPN 3251 FMI 3 | 3251 | 3 | Aftertreatment 1 Diesel Particulate Filter Differential Pressure: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 3251 FMI 4 | 3251 | 4 | Aftertreatment 1 Diesel Particulate Filter Differential Pressure: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 3362 FMI 31 | 3362 | 31 | Aftertreatment 1 Diesel Exhaust Fluid Dosing Unit 1 Input Lines: Condition Exists | ||
| SPN 3363 FMI 16 | 3363 | 16 | Aftertreatment 1 Diesel Exhaust Fluid Tank Heater: Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 3363 FMI 17 | 3363 | 17 | Aftertreatment 1 Diesel Exhaust Fluid Tank Heater: Data Valid But Below Normal Operating Range – Least Severe Level | ||
| SPN 3363 FMI 18 | 3363 | 18 | Aftertreatment 1 Diesel Exhaust Fluid Tank Heater: Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 3363 FMI 3 | 3363 | 3 | Aftertreatment 1 Diesel Exhaust Fluid Tank Heater: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 3363 FMI 4 | 3363 | 4 | Aftertreatment 1 Diesel Exhaust Fluid Tank Heater: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 3363 FMI 5 | 3363 | 5 | Aftertreatment 1 Diesel Exhaust Fluid Tank Heater: Current Below Normal Or Open Circuit | ||
| SPN 3364 FMI 13 | 3364 | 13 | Aftertreatment 1 Diesel Exhaust Fluid Tank Quality: Out Of Calibration | ||
| SPN 3464 FMI 4 | 3464 | 4 | Engine Throttle Actuator 1 Control Command: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 3464 FMI 5 | 3464 | 5 | Engine Throttle Actuator 1 Control Command: Current Below Normal Or Open Circuit | ||
| SPN 3464 FMI 9 | 3464 | 9 | Engine Throttle Actuator 1 Control Command: Abnormal Update Rate | ||
| SPN 3509 FMI 14 | 3509 | 14 | Sensor supply voltage 1: Special Instructions | ||
| SPN 3509 FMI 3 | 3509 | 3 | Sensor supply voltage 1: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 3509 FMI 4 | 3509 | 4 | Sensor supply voltage 1: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 3509 FMI 6 | 3509 | 6 | Sensor supply voltage 1: Current Above Normal Or Grounded Circuit | ||
| SPN 3510 FMI 14 | 3510 | 14 | Sensor supply voltage 2: Special Instructions | ||
| SPN 3510 FMI 3 | 3510 | 3 | Sensor supply voltage 2: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 3510 FMI 4 | 3510 | 4 | Sensor supply voltage 2: Current Above Normal Or Grounded Circuit | ||
| SPN 3510 FMI 6 | 3510 | 6 | Sensor supply voltage 2: Current Above Normal Or Grounded Circuit | ||
| SPN 3511 FMI 14 | 3511 | 14 | Sensor supply voltage 3: Special Instructions | ||
| SPN 3511 FMI 3 | 3511 | 3 | Sensor supply voltage 3: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 3511 FMI 4 | 3511 | 4 | Sensor supply voltage 3: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 3511 FMI 6 | 3511 | 6 | Sensor supply voltage 3 : Current Above Normal Or Grounded Circuit | ||
| SPN 3512 FMI 14 | 3512 | 14 | Sensor supply voltage 4: Special Instructions | ||
| SPN 3512 FMI 3 | 3512 | 3 | Sensor supply voltage 4: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 3512 FMI 4 | 3512 | 4 | Sensor supply voltage 4: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 3512 FMI 6 | 3512 | 6 | Sensor supply voltage 4: Current Above Normal Or Grounded Circuit | ||
| SPN 3515 FMI 10 | 3515 | 10 | Aftertreatment 1 Diesel Exhaust Fluid Temperature 2: Abnormal Rate Of Change | ||
| SPN 3515 FMI 20 | 3515 | 20 | Aftertreatment 1 Diesel Exhaust Fluid Temperature 2: Data Drifted High | ||
| SPN 3515 FMI 3 | 3515 | 3 | Aftertreatment 1 Diesel Exhaust Fluid Temperature 2: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 3515 FMI 4 | 3515 | 4 | Aftertreatment 1 Diesel Exhaust Fluid Temperature 2: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 3516 FMI 10 | 3516 | 10 | Aftertreatment 1 Diesel Exhaust Fluid Concentration: Abnormal Rate Of Change | ||
| SPN 3516 FMI 12 | 3516 | 12 | Aftertreatment 1 Diesel Exhaust Fluid Concentration: Bad Intelligent Device Or Component | ||
| SPN 3516 FMI 15 | 3516 | 15 | Aftertreatment 1 Diesel Exhaust Fluid Concentration: Data Valid But Above Normal Operating Range – Least Severe Level | ||
| SPN 3516 FMI 3 | 3516 | 3 | Aftertreatment 1 Diesel Exhaust Fluid Concentration: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 3516 FMI 9 | 3516 | 9 | Aftertreatment 1 Diesel Exhaust Fluid Concentration: Abnormal Update Rate | ||
| SPN 3521 FMI 14 | 3521 | 14 | Aftertreatment 1 Diesel Exhaust Fluid Property: Special Instructions | ||
| SPN 3597 FMI 3 | 3597 | 3 | ECU Power Output Supply Voltage #1: Voltage Below Normal, Or Shorted To High Source | ||
| SPN 3597 FMI 4 | 3597 | 4 | ECU Power Output Supply Voltage #1: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 3598 FMI 3 | 3598 | 3 | ECU Power Output Supply Voltage #2: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 3598 FMI 4 | 3598 | 4 | ECU Power Output Supply Voltage #2: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 3599 FMI 3 | 3599 | 3 | ECU Power Output Supply Voltage #3: Voltage Below Normal, Or Shorted To High Source | ||
| SPN 3599 FMI 4 | 3599 | 4 | ECU Power Output Supply Voltage #3: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 3605 FMI 3 | 3605 | 3 | Engine Coolant Pump Control: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 3605 FMI 4 | 3605 | 4 | Engine Coolant Pump Control: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 3605 FMI 5 | 3605 | 5 | Engine Coolant Pump Control: Current Below Normal Or Open Circuit | ||
| SPN 3610 FMI 10 | 3610 | 10 | Aftertreatment 1 Diesel Particulate Filter Outlet Pressure: Abnormal Rate Of Change | ||
| SPN 3610 FMI 16 | 3610 | 16 | Aftertreatment 1 Diesel Particulate Filter Outlet Pressure: Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 3610 FMI 2 | 3610 | 2 | Aftertreatment 1 Diesel Particulate Filter Outlet Pressure: Data Erratic, Intermittent Or Incorrect | ||
| SPN 3610 FMI 3 | 3610 | 3 | Aftertreatment 1 Diesel Particulate Filter Outlet Pressure: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 3610 FMI 4 | 3610 | 4 | Aftertreatment 1 Diesel Particulate Filter Outlet Pressure: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 3695 FMI 2 | 3695 | 2 | Aftertreatment Regeneration Inhibit Switch: Data Erratic, Intermittent Or Incorrect | ||
| SPN 3703 FMI 31 | 3703 | 31 | Diesel Particulate Filter Active Regeneration Inhibited Due to Inhibit Switch: Condition Exists | ||
| SPN 3713 FMI 31 | 3713 | 31 | Diesel Particulate Filter Active Regeneration Inhibited Due to System Timeout: Condition Exists | ||
| SPN 3750 FMI 31 | 3750 | 31 | Aftertreatment 1 Diesel Particulate Filter Conditions Not Met for Active Regeneration: Condition Exists | ||
| SPN 3936 FMI 15 | 3936 | 15 | Aftertreatment Diesel Particulate Filter System: Data Valid But Above Normal Operating Range – Least Severe Level | ||
| SPN 3936 FMI 16 | 3936 | 16 | Aftertreatment Diesel Particulate Filter System: Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 4094 FMI 31 | 4094 | 31 | NOx limits exceeded due to Insufficient Diesel Exhaust Fluid Quality: Condition Exists | ||
| SPN 412 FMI 0 | 412 | Engine Exhaust Gas Recirculation 1 Temperature: Data Valid But Above Normal Operational Range – Most Severe Level | |||
| SPN 412 FMI 2 | 412 | 2 | Engine Exhaust Gas Recirculation 1 Temperature: Data Erratic, Intermittent Or Incorrect | ||
| SPN 412 FMI 3 | 412 | 3 | Engine Exhaust Gas Recirculation 1 Temperature: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 412 FMI 4 | 412 | 4 | Engine Exhaust Gas Recirculation 1 Temperature: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 4192 FMI 3 | 4192 | 3 | Engine Fuel Filter Water Level sensor: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 4192 FMI 4 | 4192 | 4 | Engine Fuel Filter Water Level sensor: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 4227 FMI 1 | 4227 | 1 | Engine Crankcase Breather Oil Separator: Data Valid But Below Normal Operational Range – Most Severe Level | ||
| SPN 4227 FMI 8 | 4227 | 8 | Engine Crankcase Breather Oil Separator: Abnormal Frequency Or Pulse Width Or Period | ||
| SPN 4228 FMI 14 | 4228 | 14 | Engine Variable Geometry Turbocharger Actuator 1 Temperature: Special Instructions | ||
| SPN 4228 FMI 15 | 4228 | 15 | Engine Variable Geometry Turbocharger Actuator 1 Temperature: Data Valid But Above Normal Operating Range – Least Severe Level | ||
| SPN 4331 FMI 16 | 4331 | 16 | Aftertreatment 1 Diesel Exhaust Fluid Actual Dosing Quantity: Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 4331 FMI 18 | 4331 | 18 | Aftertreatment 1 Diesel Exhaust Fluid Actual Dosing Quantity: Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 4334 FMI 15 | 4334 | 15 | Aftertreatment 1 Diesel Exhaust Fluid Doser 1 Absolute Pressure: Data Valid But Above Normal Operating Range – Least Severe Level | ||
| SPN 4334 FMI 16 | 4334 | 16 | Aftertreatment 1 Diesel Exhaust Fluid Doser 1 Absolute Pressure: Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 4334 FMI 18 | 4334 | 18 | Aftertreatment 1 Diesel Exhaust Fluid Doser 1 Absolute Pressure: Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 4334 FMI 2 | 4334 | 2 | Aftertreatment 1 Diesel Exhaust Fluid Doser 1 Absolute Pressure: Data Erratic, Intermittent Or Incorrect | ||
| SPN 4334 FMI 20 | 4334 | 20 | Aftertreatment 1 Diesel Exhaust Fluid Doser 1 Absolute Pressure: Data Drifted High | ||
| SPN 4334 FMI 3 | 4334 | 3 | Aftertreatment 1 Diesel Exhaust Fluid Doser 1 Absolute Pressure: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 4334 FMI 4 | 4334 | 4 | Aftertreatment 1 Diesel Exhaust Fluid Doser 1 Absolute Pressure: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 4334 FMI 7 | 4334 | 7 | Aftertreatment 1 Diesel Exhaust Fluid Doser 1 Absolute Pressure: Mechanical System Not Responding Or Out Of Adjustment | ||
| SPN 4340 FMI 3 | 4340 | 3 | Aftertreatment 1 Diesel Exhaust Fluid Line Heater 1 State: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 4340 FMI 4 | 4340 | 4 | Aftertreatment 1 Diesel Exhaust Fluid Line Heater 1 State: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 4340 FMI 5 | 4340 | 5 | Aftertreatment 1 Diesel Exhaust Fluid Line Heater 1 State: Current Below Normal Or Open Circuit | ||
| SPN 4342 FMI 3 | 4342 | 3 | Aftertreatment 1 Diesel Exhaust Fluid Line Heater 2 State: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 4342 FMI 4 | 4342 | 4 | Aftertreatment 1 Diesel Exhaust Fluid Line Heater 2 State: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 4344 FMI 3 | 4344 | 3 | Aftertreatment 1 Diesel Exhaust Fluid Line Heater 3 State: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 4344 FMI 4 | 4344 | 4 | Aftertreatment 1 Diesel Exhaust Fluid Line Heater 3 State: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 4360 FMI 10 | 4360 | 10 | Aftertreatment 1 SCR Intake Temperature : Abnormal Rate Of Change | ||
| SPN 4360 FMI 14 | 4360 | 14 | Aftertreatment 1 SCR Intake Temperature: Special Instructions | ||
| SPN 4360 FMI 2 | 4360 | 2 | Aftertreatment 1 SCR Intake Temperature: Data Erratic, Intermittent Or Incorrect | ||
| SPN 4363 FMI 0 | 4363 | Aftertreatment 1 SCR Outlet Temperature: Data Valid But Above Normal Operational Range – Most Severe Level | |||
| SPN 4363 FMI 10 | 4363 | 10 | Aftertreatment 1 SCR Outlet Temperature : Abnormal Rate Of Change | ||
| SPN 4363 FMI 16 | 4363 | 16 | Aftertreatment 1 SCR Outlet Temperature: Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 4363 FMI 2 | 4363 | 2 | Aftertreatment 1 SCR Outlet Temperature: Data Erratic, Intermittent Or Incorrect | ||
| SPN 4363 FMI 20 | 4363 | 20 | Aftertreatment 1 SCR Outlet Temperature: Data Drifted High | ||
| SPN 4363 FMI 21 | 4363 | 21 | Aftertreatment 1 SCR Outlet Temperature: Data Drifted Low | ||
| SPN 4363 FMI 3 | 4363 | 3 | Aftertreatment 1 Selective Catalyst Reduction (SCR) Outlet Temperature: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 4363 FMI 4 | 4363 | 4 | Aftertreatment 1 SCR Outlet Temperature: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 4364 FMI 18 | 4364 | 18 | Aftertreatment 1 SCR Conversion Efficiency: Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 4374 FMI 10 | 4374 | 10 | Aftertreatment 1 Diesel Exhaust Fluid Pump 1 Motor Speed: Abnormal Rate Of Change | ||
| SPN 4374 FMI 2 | 4374 | 2 | Aftertreatment 1 Diesel Exhaust Fluid Pump 1 Motor Speed: Data Erratic, Intermittent Or Incorrect | ||
| SPN 4374 SPN 20 | 4374 | 20 | Aftertreatment 1 Diesel Exhaust Fluid Pump 1 Motor Speed : Data Drifted High | ||
| SPN 4374 SPN 31 | 4374 | 31 | Aftertreatment 1 Diesel Exhaust Fluid Pump 1 Motor Speed : Condition Exists | ||
| SPN 4375 FMI 2 | 4375 | 2 | Aftertreatment 1 Diesel Exhaust Fluid Pump Drive Percentage: Data Erratic, Intermittent Or Incorrect | ||
| SPN 4752 FMI 18 | 4752 | 18 | Engine Exhaust Gas Recirculation 1 Cooler Efficiency: Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 4765 FMI 10 | 4765 | 10 | Aftertreatment 1 Diesel Oxidation Catalyst Intake Temperature : Abnormal Rate Of Change | ||
| SPN 4765 FMI 12 | 4765 | 12 | Aftertreatment 1 Diesel Oxidation Catalyst Intake Temperature: Bad Intelligent Device Or Component | ||
| SPN 4765 FMI 16 | 4765 | 16 | Aftertreatment 1 Diesel Oxidation Catalyst Intake Temperature : Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 4765 FMI 18 | 4765 | 18 | Aftertreatment 1 Diesel Oxidation Catalyst Intake Temperature : Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 4765 FMI 2 | 4765 | 2 | Aftertreatment 1 Diesel Oxidation Catalyst Intake Temperature: Data Erratic, Intermittent Or Incorrect | ||
| SPN 4765 FMI 20 | 4765 | 20 | Aftertreatment 1 Diesel Oxidation Catalyst Intake Temperature: Data Drifted High | ||
| SPN 4765 FMI 21 | 4765 | 21 | Aftertreatment 1 Diesel Oxidation Catalyst Intake Temperature: Data Drifted Low | ||
| SPN 4765 FMI 3 | 4765 | 3 | Aftertreatment 1 Diesel Oxidation Catalyst Intake Temperature: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 4765 FMI 4 | 4765 | 4 | Aftertreatment 1 Diesel Oxidation Catalyst Intake Temperature: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 4795 FMI 31 | 4795 | 31 | Aftertreatment 1 Diesel Particulate Filter Missing: Condition Exists | ||
| SPN 5016 FMI 3 | 5016 | 3 | ECU Power Output Supply Voltage #4: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 5016 FMI 4 | 5016 | 4 | ECU Power Output Supply Voltage #4: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 5017 FMI 3 | 5017 | 3 | ECU Power Output Supply Voltage #5: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 5024 FMI 10 | 5024 | 10 | Aftertreatment 1 Intake NOx Sensor Heater Ratio: Abnormal Rate of Change | ||
| SPN 5031 FMI 10 | 5031 | 10 | Aftertreatment 1 Outlet NOx Sensor Heater Ratio: Abnormal Rate of Change | ||
| SPN 5031 FMI 2 | 5031 | 2 | Aftertreatment 1 Outlet NOx Sensor Heater Ratio : Data Erratic, Intermittent Or Incorrect | ||
| SPN 51 FMI 3 | 51 | 3 | Engine Throttle Valve 1 Position 1 : Voltage Above Normal, Or Shorted To High Source | ||
| SPN 51 FMI 4 | 51 | 4 | Engine Throttle Valve 1 Position 1 : Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 5246 FMI 0 | 5246 | Aftertreatment SCR Operator Inducement Severity: Data Valid But Above Normal Operational Range – Most Severe Level | |||
| SPN 5246 FMI 15 | 5246 | 15 | Aftertreatment SCR Operator Inducement Severity: Data Valid But Above Normal Operating Range – Least Severe Level | ||
| SPN 5246 FMI 16 | 5246 | 16 | Aftertreatment SCR Operator Inducement Severity: Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 5285 FMI 18 | 5285 | 18 | Engine Charge Air Cooler 1 Efficiency: Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 5298 FMI 18 | 5298 | 18 | Aftertreatment 1 Diesel Oxidation Catalyst Conversion Efficiency: Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 5298 SPN 17 | 5298 | 17 | Aftertreatment 1 Diesel Exhaust Fluid Pump 1 Motor Speed : Data Drifted High | ||
| SPN 5319 FMI 31 | 5319 | 31 | Aftertreatment 1 Diesel Particulate Filter Incomplete Regeneration: Condition Exists | ||
| SPN 5357 FMI 0 | 5357 | Engine Fuel Injection Quantity Error for Multiple Cylinders: Data Valid But Above Normal Operational Range – Most Severe Level | |||
| SPN 5357 FMI 1 | 5357 | 1 | Engine Fuel Injection Quantity Error for Multiple Cylinders: Data Valid But Below Normal Operational Range – Most Severe Level | ||
| SPN 5357 FMI 10 | 5357 | 10 | Engine Fuel Injection Quantity Error for Multiple Cylinders: Abnormal Rate Of Change | ||
| SPN 5357 FMI 16 | 5357 | 16 | Engine Fuel Injection Quantity Error for Multiple Cylinders: Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 5357 FMI 18 | 5357 | 18 | Engine Fuel Injection Quantity Error for Multiple Cylinders: Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 5357 FMI 31 | 5357 | 31 | Engine Fuel Injection Quantity Error for Multiple Cylinders: Condition Exists | ||
| SPN 5357 SPN 14 | 5357 | 14 | Engine Fuel Injection Quantity Error for Multiple Cylinders : Special Instructions | ||
| SPN 5358 FMI 16 | 5358 | 16 | Engine Cylinder #1 Fuel Injection Quantity: Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 5358 FMI 18 | 5358 | 18 | Engine Cylinder #1 Fuel Injection Quantity: Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 5359 FMI 16 | 5359 | 16 | Engine Cylinder #2 Fuel Injection Quantity: Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 5359 FMI 18 | 5359 | 18 | Engine Cylinder #2 Fuel Injection Quantity: Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 5360 FMI 16 | 5360 | 16 | Engine Cylinder #3 Fuel Injection Quantity: Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 5360 FMI 18 | 5360 | 18 | Engine Cylinder #3 Fuel Injection Quantity: Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 5361 FMI 16 | 5361 | 16 | Engine Cylinder #4 Fuel Injection Quantity: Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 5361 FMI 18 | 5361 | 18 | Engine Cylinder #4 Fuel Injection Quantity: Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 5362 FMI 16 | 5362 | 16 | Engine Cylinder #5 Fuel Injection Quantity: Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 5362 FMI 18 | 5362 | 18 | Engine Cylinder #5 Fuel Injection Quantity: Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 5363 FMI 16 | 5363 | 16 | Engine Cylinder #6 Fuel Injection Quantity: Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 5363 FMI 18 | 5363 | 18 | Engine Cylinder #6 Fuel Injection Quantity: Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 5376 FMI 15 | 5376 | 15 | Engine Throttle Valve 1 Temperature Status : Data Valid But Above Normal Operating Range – Least Severe Level | ||
| SPN 5376 FMI 3 | 5376 | 3 | Engine Throttle Valve 1 Temperature Status: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 5376 FMI 4 | 5376 | 4 | Engine Throttle Valve 1 Temperature Status: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 5394 FMI 3 | 5394 | 3 | Aftertreatment 1 Diesel Exhaust Fluid Doser Valve 1 : Voltage Above Normal, Or Shorted To High Source | ||
| SPN 5394 FMI 31 | 5394 | 31 | Aftertreatment 1 Diesel Exhaust Fluid Doser Valve 1: Condition Exists | ||
| SPN 5394 FMI 4 | 5394 | 4 | Aftertreatment 1 Diesel Exhaust Fluid Doser Valve 1 : Aftertreatment 1 Diesel Exhaust Fluid Doser Valve 1 : Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 5394 FMI 5 | 5394 | 5 | Aftertreatment 1 Diesel Exhaust Fluid Doser Valve 1: Current Below Normal or Open Circuit | ||
| SPN 5394 FMI 7 | 5394 | 7 | Aftertreatment 1 Diesel Exhaust Fluid Doser Valve 1: Mechanical System Not Responding Or Out Of Adjustment | ||
| SPN 5395 FMI 16 | 5395 | 16 | Engine Idle Fuel Quantity: Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 5395 FMI 18 | 5395 | 18 | Engine Idle Fuel Quantity: Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 5397 FMI 31 | 5397 | 31 | Aftertreatment 1 Diesel Particulate Filter Regeneration too Frequent: Condition Exists | ||
| SPN 5441 FMI 14 | 5441 | 14 | Engine Fuel Injection Timing Error for Multiple Cylinders : Not in SPN & FMI Descriptions | ||
| SPN 5441 FMI 31 | 5441 | 31 | Engine Fuel Injection Timing Error for Multiple Cylinders : Condition Exists | ||
| SPN 5445 FMI 12 | 5445 | 12 | Engine Throttle Valve 1 Operation Status: Bad Intelligent Device Or Component | ||
| SPN 5445 FMI 13 | 5445 | 13 | Engine Throttle Valve 1 Operation Status: Out Of Calibration | ||
| SPN 5445 FMI 14 | 5445 | 14 | Engine Throttle Valve 1 Operation Status: Special Instructions | ||
| SPN 5445 FMI 3 | 5445 | 3 | Engine Throttle Valve 1 Operation Status: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 5445 FMI 4 | 5445 | 4 | Engine Throttle Valve 1 Operation Status: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 5445 FMI 5 | 5445 | 5 | Engine Throttle Valve 1 Operation Status: Current Below Normal Or Open Circuit | ||
| SPN 5445 FMI 6 | 5445 | 6 | Engine Throttle Valve 1 Operation Status: Current Above Normal Or Grounded Circuit | ||
| SPN 5491 FMI 3 | 5491 | 3 | Aftertreatment 1 Diesel Exhaust Fluid Line Heater Relay 1: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 5491 FMI 4 | 5491 | 4 | Aftertreatment 1 Diesel Exhaust Fluid Line Heater Relay 1: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 5548 FMI 1 | 5548 | 1 | Engine Cold Start Fuel Igniter Command: Data Valid But Below Normal Operational Range – Most Severe Level | ||
| SPN 5548 FMI 3 | 5548 | 3 | Engine Cold Start Fuel Igniter Command: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 5548 FMI 4 | 5548 | 4 | Engine Cold Start Fuel Igniter Command: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 5548 FMI 5 | 5548 | 5 | Engine Cold Start Fuel Igniter Command: Current Below Normal Or Open Circuit | ||
| SPN 5548 FMI 8 | 5548 | 8 | Engine Cold Start Fuel Igniter Command: Abnormal Frequency Or Pulse Width Or Period | ||
| SPN 5569 FMI 16 | 5569 | 16 | Diesel Particulate Filter 1 Soot Sensor ECU Internal Temperature: Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 5569 FMI 2 | 5569 | 2 | Diesel Particulate Filter 1 Soot Sensor ECU Internal Temperature: Data Erratic, Intermittent Or Incorrect | ||
| SPN 5569 FMI 3 | 5569 | 3 | Diesel Particulate Filter 1 Soot Sensor ECU Internal Temperature: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 5569 FMI 4 | 5569 | 4 | Diesel Particulate Filter 1 Soot Sensor ECU Internal Temperature: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 5585 FMI 1 | 5585 | 1 | Engine Fuel 1 Injector Metering Rail 1 Cranking Pressure: Data Valid But Below Normal Operational Range – Most Severe Level | ||
| SPN 560 FMI 2 | 560 | 2 | Transmission Driveline Engaged: Data Erratic, Intermittent Or Incorrect | ||
| SPN 5742 FMI 12 | 5742 | 12 | Aftertreatment Diesel Particulate Filter Temperature Sensor Module: Bad Intelligent Device Or Component | ||
| SPN 5742 FMI 16 | 5742 | 16 | Aftertreatment Diesel Particulate Filter Temperature Sensor Module: Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 5742 FMI 3 | 5742 | 3 | Aftertreatment Diesel Particulate Filter Temperature Sensor Module: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 5742 FMI 4 | 5742 | 4 | Aftertreatment Diesel Particulate Filter Temperature Sensor Module: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 5742 FMI 9 | 5742 | 9 | Aftertreatment Diesel Particulate Filter Temperature Sensor Module: Abnormal Update Rate | ||
| SPN 5743 FMI 9 | 5743 | 9 | Aftertreatment 1 SCR Temperature Sensor Module: Abnormal Update Rate | ||
| SPN 5747 FMI 10 | 5747 | 10 | Aftertreatment 1 Outlet Soot Sensor Heater: Abnormal Rate Of Change | ||
| SPN 5747 FMI 3 | 5747 | 3 | Aftertreatment 1 Outlet Soot Sensor Heater: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 5747 FMI 4 | 5747 | 4 | Aftertreatment 1 Outlet Soot Sensor Heater: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 5747 FMI 5 | 5747 | 5 | Aftertreatment 1 Outlet Soot Sensor Heater: Current Below Normal Or Open Circuit | ||
| SPN 5765 FMI 14 | 5765 | 14 | Engine Exhaust Gas Recirculation 1 Actuator 1 Temperature: Special Instructions | ||
| SPN 5765 FMI 15 | 5765 | 15 | Engine Exhaust Gas Recirculation 1 Actuator 1 Temperature: Data Valid But Above Normal Operating Range – Least Severe Level | ||
| SPN 5835 FMI 21 | 5835 | 21 | Aftertreatment 1 Particulate Sensor: Data Drifted Low | ||
| SPN 5835 FMI 3 | 5835 | 3 | Aftertreatment 1 Particulate Sensor: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 5835 FMI 4 | 5835 | 4 | Aftertreatment 1 Particulate Sensor: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 5835 FMI 9 | 5835 | 9 | Aftertreatment 1 Particulate Sensor: Abnormal Update Rate | ||
| SPN 5927 FMI 0 | 5927 | Engine Coolant Pump: Data Valid But Above Normal Operational Range – Most Severe Level | |||
| SPN 5927 FMI 3 | 5927 | 3 | Engine Coolant Pump: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 5927 FMI 4 | 5927 | 4 | Engine Coolant Pump: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 597 FMI 19 | 597 | 19 | Brake Switch: Received Network Data In Error | ||
| SPN 6216 FMI 31 | 6216 | 31 | Engine Ignition Control Module 1 State: Condition Exists | ||
| SPN 625 FMI 19 | 625 | 19 | Proprietary Network #1: Received Network Data In Error | ||
| SPN 626 FMI 3 | 626 | 3 | Engine Start Enable Device 1: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 626 FMI 4 | 626 | 4 | Engine Start Enable Device 1: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 626 FMI 5 | 626 | 5 | Engine Start Enable Device 1: Current Below Normal Or Open Circuit | ||
| SPN 629 FMI 0 | 629 | Controller #1 : Data Valid But Above Normal Operational Range – Most Severe Level | |||
| SPN 629 FMI 12 | 629 | 12 | Controller #1: Bad Intelligent Device Or Component | ||
| SPN 629 FMI 15 | 629 | 15 | Controller #1: Data Valid But Above Normal Operating Range – Least Severe Level | ||
| SPN 629 FMI 31 | 629 | 31 | Controller #1 : Condition Exists | ||
| SPN 633 FMI 0 | 633 | Engine Fuel Actuator 1 Control Command: Data Valid But Above Normal Operational Range – Most Severe Level | |||
| SPN 633 FMI 20 | 633 | 20 | Engine Fuel Actuator 1 Control Command : Data Drifted High | ||
| SPN 633 FMI 21 | 633 | 21 | Engine Fuel Actuator 1 Control Command : Data Drifted Low | ||
| SPN 633 FMI 3 | 633 | 3 | Engine Fuel Actuator 1 Control Command: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 633 FMI 4 | 633 | 4 | Engine Fuel Actuator 1 Control Command: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 636 FMI 10 | 636 | 10 | Engine Position Sensor: Abnormal Rate Of Change | ||
| SPN 636 FMI 2 | 636 | 2 | Engine Position Sensor: Data Erratic, Intermittent Or Incorrect | ||
| SPN 636 FMI 3 | 636 | 3 | Engine Position Sensor: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 636 FMI 4 | 636 | 4 | Engine Position Sensor: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 636 FMI 8 | 636 | 8 | Engine Position Sensor: Abnormal Frequency Or Pulse Width Or Period | ||
| SPN 637 FMI 10 | 637 | 10 | Engine Timing Sensor: Abnormal Rate Of Change | ||
| SPN 637 FMI 3 | 637 | 3 | Engine Timing Sensor: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 637 FMI 4 | 637 | 4 | Engine Timing Sensor: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 637 FMI 8 | 637 | 8 | Engine Timing Sensor: Abnormal Frequency Or Pulse Width Or Period | ||
| SPN 639 FMI 19 | 639 | 19 | J1939 Network #1, Primary Vehicle Network: Received Network Data In Error | ||
| SPN 639 FMI 9 | 639 | 9 | J1939 Network #1, Primary Vehicle Network: Abnormal Update Rate | ||
| SPN 641 FMI 12 | 641 | 12 | Engine Variable Geometry Turbocharger Actuator #1: Bad Intelligent Device Or Component | ||
| SPN 641 FMI 14 | 641 | 14 | Engine Variable Geometry Turbocharger Actuator #1: Special Instructions | ||
| SPN 641 FMI 2 | 641 | 2 | Engine Variable Geometry Turbocharger Actuator #1: Data Erratic, Intermittent Or Incorrect | ||
| SPN 641 FMI 7 | 641 | 7 | Engine Variable Geometry Turbocharger Actuator #1: Mechanical System Not Responding Or Out Of Adjustment | ||
| SPN 641 FMI 9 | 641 | 9 | Engine Variable Geometry Turbocharger Actuator #1: Abnormal Update Rate | ||
| SPN 651 FMI 13 | 651 | 13 | Engine Fuel 1 Injector Cylinder 1: Out Of Calibration | ||
| SPN 651 FMI 3 | 651 | 3 | Engine Fuel 1 Injector Cylinder 1: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 651 FMI 4 | 651 | 4 | Engine Fuel 1 Injector Cylinder 1: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 651 FMI 5 | 651 | 5 | Engine Fuel 1 Injector Cylinder 1 : Current Below Normal or Open Circuit | ||
| SPN 652 FMI 13 | 652 | 13 | Engine Fuel 1 Injector Cylinder 2: Out Of Calibration | ||
| SPN 652 FMI 3 | 652 | 3 | Engine Fuel 1 Injector Cylinder 2: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 652 FMI 4 | 652 | 4 | Engine Fuel 1 Injector Cylinder 2: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 652 FMI 5 | 652 | 5 | Engine Fuel 1 Injector Cylinder 2: Current Below Normal or Open Circuit | ||
| SPN 653 FMI 13 | 653 | 13 | Engine Fuel 1 Injector Cylinder 3: Out Of Calibration | ||
| SPN 653 FMI 3 | 653 | 3 | Engine Fuel 1 Injector Cylinder 3: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 653 FMI 4 | 653 | 4 | Engine Fuel 1 Injector Cylinder 3: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 653 FMI 5 | 653 | 5 | Engine Fuel 1 Injector Cylinder 3: Current Below Normal or Open Circuit | ||
| SPN 654 FMI 13 | 654 | 13 | Engine Fuel 1 Injector Cylinder 4: Out Of Calibration | ||
| SPN 654 FMI 3 | 654 | 3 | Engine Fuel 1 Injector Cylinder 4: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 654 FMI 4 | 654 | 4 | Engine Fuel 1 Injector Cylinder 4: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 654 FMI 5 | 654 | 5 | Engine Fuel 1 Injector Cylinder 4: Current Below Normal or Open Circuit | ||
| SPN 655 FMI 13 | 655 | 13 | Engine Fuel 1 Injector Cylinder 5: Out Of Calibration | ||
| SPN 655 FMI 3 | 655 | 3 | Engine Fuel 1 Injector Cylinder 5: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 655 FMI 4 | 655 | 4 | Engine Fuel 1 Injector Cylinder 5: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 655 FMI 5 | 655 | 5 | Engine Fuel 1 Injector Cylinder 5: Current Below Normal or Open Circuit | ||
| SPN 656 FMI 13 | 656 | 13 | Engine Fuel 1 Injector Cylinder 6: Out Of Calibration | ||
| SPN 656 FMI 3 | 656 | 3 | Engine Fuel 1 Injector Cylinder 6: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 656 FMI 4 | 656 | 4 | Engine Fuel 1 Injector Cylinder 6: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 656 FMI 5 | 656 | 5 | Engine Fuel 1 Injector Cylinder 6: Current Below Normal or Open Circuit | ||
| SPN 6589 FMI 16 | 6589 | 16 | Engine Fuel 1 Injector Metering Rail 1 Pressure 1: Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 6589 FMI 18 | 6589 | 18 | Engine Fuel 1 Injector Metering Rail 1 Pressure 1: Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 6589 FMI 3 | 6589 | 3 | Engine Fuel 1 Injector Metering Rail 1 Pressure 1: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 6589 FMI 4 | 6589 | 4 | Engine Fuel 1 Injector Metering Rail 1 Pressure 1: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 6590 FMI 16 | 6590 | 16 | Engine Fuel 1 Injector Metering Rail 1 Pressure 2: Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 6590 FMI 18 | 6590 | 18 | Engine Fuel 1 Injector Metering Rail 1 Pressure 2: Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 6590 FMI 3 | 6590 | 3 | Engine Fuel 1 Injector Metering Rail 1 Pressure 2: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 6590 FMI 4 | 6590 | 4 | Engine Fuel 1 Injector Metering Rail 1 Pressure 2: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 6653 FMI 16 | 6653 | 16 | Engine Fuel 1 Injector Metering Rail 1 Cold Start Pressure: Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 6653 FMI 18 | 6653 | 18 | Engine Fuel 1 Injector Metering Rail 1 Cold Start Pressure: Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 6719 FMI 7 | 6719 | 7 | Engine Fuel Injection Pump 1 Fuel Control Valve Command: Mechanical System Not Responding Or Out Of Adjustment | ||
| SPN 6774 FMI 7 | 6774 | 7 | Aftertreatment 1 Particulate Sensor Regeneration State: Mechanical System Not Responding Or Out Of Adjustment | ||
| SPN 6778 FMI 16 | 6778 | 16 | Aftertreatment 1 Particulate Sensor Power Supply: Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 6778 FMI 3 | 6778 | 3 | Aftertreatment 1 Particulate Sensor Power Supply: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 6778 FMI 4 | 6778 | 4 | Aftertreatment 1 Particulate Sensor Power Supply: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 6780 FMI 2 | 6780 | 2 | Aftertreatment 1 Particulate Sensor Temperature: Data Erratic, Intermittent or Incorrect | ||
| SPN 6780 FMI 3 | 6780 | 3 | Aftertreatment 1 Particulate Sensor Temperature: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 6780 FMI 4 | 6780 | 4 | Aftertreatment 1 Particulate Sensor Temperature: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 6889 FMI 3 | 6889 | 3 | Engine Turbocharger Wastegate Actuator 1 Power Supply : Voltage Above Normal, Or Shorted To High Source | ||
| SPN 6889 FMI 4 | 6889 | 4 | Engine Turbocharger Wastegate Actuator 1 Power Supply : Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 69 FMI 19 | 69 | 19 | Two Speed Axle Switch : Received Network Data In Error | ||
| SPN 7026 FMI 19 | 7026 | 19 | Engine Diesel Fuel Metering Valve : Received Network Data In Error | ||
| SPN 70 FMI 19 | 70 | 19 | Parking Brake Switch: Received Network Data In Error | ||
| SPN 7100 FMI 7 | 7100 | 7 | Engine Fuel 1 Injector Metering Rail 1 Desired Pressure : Mechanical System Not Responding Or Out Of Adjustment | ||
| SPN 7107 FMI 3 | 7107 | 3 | Aftertreatment 1 Diesel Exhaust Fluid Pump: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 7107 FMI 4 | 7107 | 4 | Aftertreatment 1 Diesel Exhaust Fluid Pump: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 724 FMI 16 | 724 | 16 | O2 Sensor: Data Valid But Above Normal Operating Range – Moderately Severe Level | ||
| SPN 7330 FMI 2 | 7330 | 2 | Aftertreatment 1 Particulate Sensor Heater Power Supply Diagnostic Status: Data Erratic, Intermittent Or Incorrect | ||
| SPN 7393 FMI 10 | 7393 | 10 | Aftertreatment 1 Particulate Sensor Current: Abnormal Rate Of Change | ||
| SPN 7393 FMI 2 | 7393 | 2 | Aftertreatment 1 Particulate Sensor Current: Data Erratic, Intermittent Or Incorrect | ||
| SPN 7416 FMI 3 | 7416 | 3 | Aftertreatment 1 Diesel Exhaust Fluid Pump Power Relay: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 7416 FMI 4 | 7416 | 4 | Aftertreatment 1 Diesel Exhaust Fluid Pump Power Relay: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 7854 FMI 2 | 7854 | 2 | Aftertreatment 1 Particulate Sensor Module: Data Erratic, Intermittent Or Incorrect | ||
| SPN 84 FMI 0 | 84 | Wheel-Based Vehicle Speed: Data Valid But Above Normal Operational Range – Most Severe Level | |||
| SPN 84 FMI 1 | 84 | 1 | Wheel-Based Vehicle Speed: Data Valid But Below Normal Operational Range – Most Severe Level | ||
| SPN 84 FMI 15 | 84 | 15 | Wheel-Based Vehicle Speed: Data Valid But Above Normal Operating Range – Least Severe Level | ||
| SPN 84 FMI 3 | 84 | 3 | Wheel-Based Vehicle Speed: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 84 FMI 4 | 84 | 4 | Wheel-Based Vehicle Speed: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 91 FMI 2 | 91 | 2 | Accelerator Pedal Position 1: Data Erratic, Intermittent Or Incorrect | ||
| SPN 91 FMI 3 | 91 | 3 | Accelerator Pedal Position 1: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 91 FMI 4 | 91 | 4 | Accelerator Pedal Position 1: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 974 FMI 19 | 974 | 19 | Remote Accelerator Pedal Position : Received Network Data In Error | ||
| SPN 974 FMI 3 | 974 | 3 | Remote Accelerator Pedal Position: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 974 FMI 4 | 974 | 4 | Remote Accelerator Pedal Position: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 977 FMI 3 | 977 | 3 | Fan Drive State: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 977 FMI 4 | 977 | 4 | Fan Drive State: Voltage Below Normal, Or Shorted To Low Source | ||
| SPN 977 FMI 5 | 977 | 5 | Fan Drive State: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 97 FMI 31 | 97 | 31 | Water In Fuel Indicator 1: Condition Exists | ||
| SPN 98 FMI 14 | 98 | 14 | Engine Oil Level: Special Instructions | ||
| SPN 98 FMI 17 | 98 | 17 | Engine Oil Level: Data Valid But Below Normal Operating Range – Least Severe Level | ||
| SPN 98 FMI 3 | 98 | 3 | Engine Oil Level: Voltage Above Normal, Or Shorted To High Source | ||
| SPN 98 FMI 4 | 98 | 4 | Engine Oil Level: Voltage Below Normal, Or Shorted To Low Source |
For full access to International A26 (2024–2025) repair data, wiring diagrams, troubleshooting guides and more, sign up for a free Diesel Repair account today!
📱 Now Available: Diesel Repair Mobile App
Access fault codes, wiring diagrams, and repair docs right from your phone or tablet—whether you’re in the shop or roadside. The Diesel Repair mobile app is live and ready to keep techs connected on every job.
