The Cummins ISB6.7 is one of the most widely used medium-duty diesel engines across North America, powering everything from delivery trucks to school buses. Known for its durability and fuel efficiency, this engine plays a key role in fleet uptime—and when a fault code appears, quick diagnosis is critical.
That’s why Diesel Repair offers a fast, centralized way to access Cummins ISB6.7 fault code information.
Cummins ISB6.7 Engine Overview
- Displacement: 6.7L
- Horsepower Range: 200–360 HP
- Torque: Up to 800 lb-ft
- Emissions System: SCR + DPF + EGR
- Fuel System: High-Pressure Common Rail (HPCR)
- Applications: Freightliner M2, International MV Series, Ford F-650, school buses, and more
📍 Get FREE Fault Code Information for all makes and models in Diesel Repair → Diesel Repair
Fault Codes for Caterpillar C15 (2007–2011)
Fault Codes for Cummins ISB6.7
| Fault | PID | SPN | FMI | SID | Title |
| SPN 100 FMI 1 (415) | 100 | 100 | 1 | Engine Oil Rifle Pressure – Data Valid But Below Normal Operational Range – Most Severe Level | |
| SPN 100 FMI 18 (143) | 100 | 100 | 18 | Engine Oil Rifle Pressure – Data Valid But Below Normal Operational Range – Moderately Severe Level | |
| SPN 100 FMI 2 (435) | 100 | 100 | 2 | Engine Oil Rifle Pressure – Data Erratic, Intermittent, or Incorrect | |
| SPN 100 FMI 3 (135) | 100 | 100 | 3 | Engine Oil Rifle Pressure 1 Sensor Circuit – Voltage Above Normal or Shorted to High Source | |
| SPN 100 FMI 4 (141) | 100 | 100 | 4 | Engine Oil Rifle Pressure 1 Sensor Circuit – Voltage Below Normal or Shorted to Low Source | |
| SPN 101 FMI 0 (556) | 101 | 101 | Crankcase Pressure – Data Valid But Above Normal Operational Range – Most Severe Level | ||
| SPN 101 FMI 15 (1974) | 101 | 101 | 15 | Crankcase Pressure – Data Valid But Above Normal Operational Range – Least Severe Level | |
| SPN 101 FMI 16 (555) | 101 | 101 | 16 | Crankcase Pressure – Data Valid But Above Normal Operational Range – Moderately Severe Level | |
| SPN 101 FMI 2 (1942) | 101 | 101 | 2 | Crankcase Pressure – Data Erratic, Intermittent, or Incorrect | |
| SPN 101 FMI 3 (1843) | 101 | 101 | 3 | Crankcase Pressure Circuit – Voltage Above Normal or Shorted to High Source | |
| SPN 101 FMI 4 (1844) | 101 | 101 | 4 | Crankcase Pressure Circuit – Voltage Below Normal or Shorted to Low Source | |
| SPN 102 FMI 2 (2973) | 102 | 102 | 2 | Intake Manifold 1 Pressure – Data Erratic, Intermittent, or Incorrect | |
| SPN 102 FMI 3 (122) | 102 | 102 | 3 | Intake Manifold 1 Pressure Sensor Circuit – Voltage Above Normal or Shorted to High Source | |
| SPN 102 FMI 4 (123) | 102 | 102 | 4 | Intake Manifold 1 Pressure Sensor Circuit – Voltage Below Normal or Shorted to Low Source | |
| SPN 103 FMI 10 (2345) | 103 | 103 | 10 | Turbocharger 1 Speed – Abnormal Rate of Change | |
| SPN 103 FMI 15 (2288) | 103 | 103 | 15 | Turbocharger 1 Speed – Data Valid But Above Normal Operational Range – Least Severe Level | |
| SPN 103 FMI 18 (687) | 103 | 103 | 18 | Turbocharger 1 Speed – Data Valid But Below Normal Operating Range – Moderately Severe Level | |
| SPN 103 FMI 2 (686) | 103 | 103 | 2 | Turbocharger 1 Speed – Data Erratic, Intermittent, or Incorrect | |
| SPN 105 FMI 0 (155) | 105 | 105 | Intake Manifold 1 Temperature – Data Valid but Above Normal Operational Range – Most Severe Level | ||
| SPN 105 FMI 15 (2964) | 105 | 105 | 15 | Intake Manifold 1 Temperature – Data Valid But Above Normal Operational Range – Least Severe Level | |
| SPN 105 FMI 16 (488) | 105 | 105 | 16 | Intake Manifold 1 Temperature – Data Valid But Above Normal Operational Range – Moderately Severe Level | |
| SPN 105 FMI 3 (153) | 105 | 105 | 3 | Intake Manifold 1 Temperature Sensor Circuit – Voltage Above Normal or Shorted to High Source | |
| SPN 105 FMI 4 (154) | 105 | 105 | 4 | Intake Manifold 1 Temperature Sensor Circuit – Voltage Below Normal or Shorted to Low Source | |
| SPN 1072 FMI 3 (2182) | SID 79 | 1072 | 3 | Engine Brake Actuator Driver 1 Circuit – Voltage Above Normal or Shorted to High Source | |
| SPN 1072 FMI 4 (2183) | 1072 | 4 | 79 | Engine Brake Actuator Circuit 1 – Voltage Below Normal or Shorted to Low Source | |
| SPN 1073 FMI 3 (2367) | 1073 | 3 | 80 | Engine Brake Actuator Driver Output 2 Circuit – Voltage Above Normal or Shorted to High Source | |
| SPN 1073 FMI 4 (2363) | 1073 | 4 | 29 | Engine Brake Actuator Driver Output 2 Circuit – Voltage Below Normal or Shorted to Low Source | |
| SPN 1075 FMI 3 (2265) | 1075 | 3 | 126 | Electric Lift Pump for Engine Fuel Supply Circuit – Voltage Above Normal or Shorted to High Source | |
| SPN 1075 FMI 4 (2266) | 1075 | 4 | 126 | Electric Lift Pump for Engine Fuel Supply Circuit – Voltage Below Normal or Shorted to Low Source | |
| SPN 108 FMI 2 (295) | 108 | 108 | 2 | Barometric Pressure – Data Erratic, Intermittent, or Incorrect | |
| SPN 108 FMI 3 (221) | 108 | 108 | 3 | Barometric Pressure Sensor Circuit – Voltage Above Normal or Shorted to High Source | |
| SPN 108 FMI 4 (222) | 108 | 108 | 4 | Barometric Pressure Sensor Circuit – Voltage Below Normal or Shorted to Low Source | |
| SPN 110 FMI 0 (151) | 110 | 110 | Engine Coolant Temperature – Data Valid But Above Normal Operational Range – Most Severe Level | ||
| SPN 110 FMI 15 (2963) | 110 | 110 | 15 | Engine Coolant Temperature – Data Valid But Above Normal Operational Range – Least Severe Level | |
| SPN 110 FMI 16 (146) | 110 | 110 | 16 | Engine Coolant Temperature – Data Valid But Above Normal Operational Range – Moderately Severe Level | |
| SPN 110 FMI 31 (2646) | 110 | 110 | 31 | Engine Coolant Temperature – Condition Exists | |
| SPN 110 FMI 31 (2659) | 110 | 110 | 31 | Engine Coolant Temperature – Condition Exists | |
| SPN 110 FMI 3 (144) | 110 | 110 | 3 | Engine Coolant Temperature 1 Sensor Circuit – Voltage Above Normal or Shorted to High Source | |
| SPN 110 FMI 4 (145) | 110 | 110 | 4 | Engine Coolant Temperature 1 Sensor Circuit – Voltage Below Normal or Shorted to Low Source | |
| SPN 111 FMI 17 (2448) | 111 | 17 | Coolant Level – Data Valid But Below Normal Operational Range – Least Severe Level | ||
| SPN 111 FMI 18 (197) | 111 | 111 | 18 | Coolant Level – Data Valid But Below Normal Operating Range – Moderately Severe Level | |
| SPN 111 FMI 3 (195) | 111 | 111 | 3 | Coolant Level Sensor 1 Circuit – Voltage Above Normal or Shorted to High Source | |
| SPN 111 FMI 3 (195) | 111 | 111 | 3 | Coolant Level Sensor 1 Circuit – Voltage Above Normal or Shorted to High Source | |
| SPN 111 FMI 4 (196) | 111 | 111 | 4 | Coolant Level Sensor 1 Circuit – Voltage Below Normal or Shorted to Low Source | |
| SPN 111 FMI 4 (196) | 111 | 111 | 4 | Coolant Level Sensor 1 Circuit – Voltage Below Normal or Shorted to Low Source | |
| SPN 1136 FMI 4 (698) | 21 | 1136 | 4 | ECM Internal Temperature Sensor Circuit – Voltage Below Normal or Shorted to Low Source | |
| SPN 1172 FMI 3 (691) | 351 | 1172 | 3 | Turbocharger 1 Compressor Inlet Temperature Sensor Circuit – Voltage Above Normal or Shorted to High Source | |
| SPN 1172 FMI 4 (692) | 351 | 1172 | 4 | Turbocharger 1 Compressor Inlet Temperature Sensor Circuit – Voltage Below Normal or Shorted to Low Source | |
| SPN 1209 FMI 2 (2554) | 131 | 1209 | 2 | Exhaust Gas Pressure – Data Erratic, Intermittent, or Incorrect | |
| SPN 1209 FMI 3 (2373) | 131 | 1209 | 3 | Exhaust Gas Pressure Sensor Circuit – Voltage Above Normal or Shorted to High Source | |
| SPN 1209 FMI 4 (2374) | 131 | 1209 | 4 | Exhaust Gas Pressure Sensor Circuit – Voltage Below Normal or Shorted to Low Source | |
| SPN 1347 FMI 3 (272) | 1347 | 3 | 126 | Fuel Pump Pressurizing Assembly 1 Circuit – Voltage Above Normal or Shorted to High Source | |
| SPN 1347 FMI 4 (271) | 1347 | 4 | 126 | Fuel Pump Pressurizing Assembly 1 Circuit – Voltage Below Normal or Shorted to Low Source | |
| SPN 1347 FMI 7 (281) | 1347 | 7 | 126 | Fuel Pump Pressurizing Assembly 1 – Mechanical System Not Responding Properly or Out of Adjustment | |
| SPN 1378 FMI 31 (649) | 1378 | 31 | 115 | Engine Oil Change Interval – Condition Exists | |
| SPN 157 FMI 0 (1911) | 157 | 157 | Injector Metering Rail Number 1 Pressure – Data Valid But Above Normal Operating Range – Most Severe Level | ||
| SPN 157 FMI 0 (449) | 94 | 157 | Injector Metering Rail Number 1 Pressure – Data Valid But Above Normal Operating Range – Most Severe Level | ||
| SPN 157 FMI 16 (553) | 157 | 157 | 16 | Injector Metering Rail Number 1 Pressure – Data Valid But Above Normal Operating Range – Moderately Severe Level | |
| SPN 157 FMI 18 (559) | 157 | 157 | 18 | Injector Metering Rail 1 Pressure – Data Valid But Below Normal Operating Range – Moderately Severe Level | |
| SPN 157 FMI 2 (554) | 157 | 157 | 2 | Injector Metering Rail 1 Pressure – Data Erratic, Intermittent, or Incorrect | |
| SPN 157 FMI 3 (451) | 157 | 157 | 3 | Injector Metering Rail Number 1 Pressure Sensor Circuit – Voltage Above Normal or Shorted to High Source | |
| SPN 157 FMI 4 (452) | 157 | 157 | 4 | Injector Metering Rail Number 1 Pressure Sensor Circuit – Voltage Below Normal or Shorted to Low Source | |
| SPN 1590 FMI 2 (784) | 1590 | 2 | 145 | Adaptive Cruise Control Mode – Data Erratic, Intermittent, or Incorrect | |
| SPN 167 FMI 1 (598) | 167 | 167 | 1 | Electrical Charging System Voltage – Data Valid But Below Normal Operating Range – Most Severe Level | |
| SPN 167 FMI 16 (596) | 167 | 167 | 16 | Electrical Charging System Voltage – Data Valid But Above Normal Operating Range – Moderately Severe Level | |
| SPN 167 FMI 18 (597) | 167 | 167 | 18 | Electrical Charging System Voltage – Data Valid But Below Normal Operating Range – Moderately Severe Level | |
| SPN 168 FMI 16 (442) | 168 | 168 | 16 | Battery 1 Voltage – Data Valid But Above Normal Operational Range – Moderately Severe Level | |
| SPN 168 FMI 18 (441) | 168 | 168 | 18 | Battery 1 Voltage – Data Valid But Below Normal Operational Range – Moderately Severe Level | |
| SPN 171 FMI 3 (249) | 171 | 171 | 3 | Ambient Air Temperature Sensor 1 Circuit – Voltage Above Normal or Shorted to High Source | |
| SPN 171 FMI 4 (256) | 171 | 171 | 4 | Ambient Air Temperature Sensor 1 Circuit – Voltage Below Normal or Shorted to Low Source | |
| SPN 190 FMI 0 (234) | 190 | 190 | Engine Crankshaft Speed / Position – Data Valid But Above Normal Operational Range – Most Severe Level | ||
| SPN 190 FMI 2 (2321) | 190 | 190 | 2 | Engine Crankshaft Speed / Position – Data Erratic, Intermittent, or Incorrect | |
| SPN 190 FMI 2 (689) | 190 | 190 | 2 | Engine Crankshaft Speed / Position – Data Erratic, Intermittent, or Incorrect | |
| SPN 2623 FMI 3 (1239) | 2623 | 3 | Accelerator Pedal or Lever Position Sensor 2 Circuit – Voltage Above Normal or Shorted to High Source | ||
| SPN 2623 FMI 4 (1241) | 2623 | 4 | Accelerator Pedal or Lever Position Sensor 2 Circuit – Voltage Below Normal or Shorted to Low Source | ||
| SPN 2633 (3616) | 2633 | Variable Geometry Turbocharger (VGT) Actuator Position – Special Instructions | |||
| SPN 2789 FMI 15 (2346) | 2789 | 15 | Turbocharger Turbine Inlet Temperature (Calculated) – Data Valid But Above Normal Operational Range – Least Severe Level | ||
| SPN 2789 FMI 16 (2451) | 2789 | 16 | Turbocharger Turbine Inlet Temperature (Calculated) – Data Valid But Above Normal Operational Range – Moderately Severe Level | ||
| SPN 2790 FMI 15 (2347) | 2790 | 15 | Turbocharger Compressor Outlet Temperature (Calculated) – Data Valid But Above Normal Operational Range – Least Severe Level | ||
| SPN 2791 FMI 13 (1896) | 2791 | 13 | 146 | EGR Valve Controller – Out of Calibration | |
| SPN 2791 FMI 14 (2813) | 146 | 2791 | 14 | EGR Valve Control – Special Instructions | |
| SPN 2791 FMI 4 (2351) | 2791 | 4 | 146 | EGR Valve Control Circuit – Voltage Below Normal or Shorted to Low Source | |
| SPN 2791 FMI 5 (2349) | 2791 | 5 | 146 | EGR Valve Control Circuit – Current Below Normal or Open Circuit | |
| SPN 2791 FMI 7 (2357) | 2791 | 7 | 146 | EGR Valve Control Circuit – Mechanical System Not Responding Properly or Out of Adjustment | |
| SPN 2797 FMI 13 (2765) | 2797 | 13 | Engine Injector Bank 1 Barcodes – Out of Calibration | ||
| SPN 27 FMI 4 (2272) | 27 | 27 | 4 | EGR Valve Position Circuit – Voltage Below Normal or Shorted to Low Source | |
| SPN 3050 FMI 11 (2637) | 3050 | 11 | Catalyst Face Plugged – Root Cause Not Known | ||
| SPN 3050 FMI 13 (2638) | 3050 | 13 | Catalyst Efficiency – Out of Calibration | ||
| SPN 3050 FMI 31 (1664) | 3050 | 31 | Catalyst Missing – Condition Exists | ||
| SPN 3064 FMI 31 (1993) | 3064 | 31 | Aftertreatment Particulate Trap Missing – Condition Exists | ||
| SPN 3241 FMI 0 (1966) | 326 | 3241 | Aftertreatment Exhaust Gas Temperature 1 – Data Valid But Above Normal Operating Range – Most Severe Level | ||
| SPN 3241 FMI 2 (1667) | 3241 | 2 | Aftertreatment Exhaust Gas Temperature 1 – Data Erratic, Intermittent, or Incorrect | ||
| SPN 3241 FMI 31 (1663) | 3241 | 31 | Catalyst Inlet Temperature Sensor Swapped with Outlet – Condition Exists | ||
| SPN 3241 FMI 3 (1666) | 3241 | 3 | Aftertreatment Exhaust Gas Temperature 1 Circuit – Voltage Above Normal or Shorted to High Source | ||
| SPN 3241 FMI 4 (1665) | 3241 | 4 | Aftertreatment Exhaust Gas Temperature 1 Circuit – Voltage Below Normal or Shorted to Low Source | ||
| SPN 3245 FMI 0 (1973) | 3245 | Exhaust Gas Temperature 3 – Data Valid But Above Normal Operational Range – Most Severe Level | |||
| SPN 3245 FMI 16 (1972) | 3245 | 16 | Exhaust Gas Temperature 3 – Data Valid But Above Normal Operational Range – Moderately Severe Level | ||
| SPN 3245 FMI 2 (1878) | 3245 | 2 | Aftertreatment Exhaust Gas Temperature 3 – Data Erratic, Intermittent, or Incorrect | ||
| SPN 3245 FMI 3 (1876) | 3245 | 3 | Aftertreatment Exhaust Gas Temperature 3 Circuit – Voltage Above Normal or Shorted to High Source | ||
| SPN 3245 FMI 4 (1877) | 3245 | 4 | Aftertreatment Exhaust Gas Temperature 3 Circuit – Voltage Below Normal or Shorted to Low Source | ||
| SPN 3249 FMI 0 (1969) | 3249 | Aftertreatment Exhaust Gas Temperature 2 – Data Valid But Above Normal Operational Range – Most Severe Level | |||
| SPN 3249 FMI 16 (1968) | 3249 | 16 | Aftertreatment Exhaust Gas Temperature 2 – Data Valid But Above Normal Operational Range – Moderately Severe Level | ||
| SPN 3249 FMI 17 (2742) | 3249 | 17 | Aftertreatment Exhaust Gas Temperature 2 – Data Valid But Below Normal Operating Range – Least Severe Level | ||
| SPN 3249 FMI 18 (2743) | 3249 | 18 | Aftertreatment Exhaust Gas Temperature 2 – Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 3249 FMI 2 (1676) | 3249 | 2 | Aftertreatment Exhaust Gas Temperature 2 – Data Erratic, Intermittent, or Incorrect | ||
| SPN 3249 FMI 3 (1675) | 3249 | 3 | Aftertreatment Exhaust Gas Temperature 2 Circuit – Voltage Above Normal or Shorted to High Source | ||
| SPN 3249 FMI 4 (1674) | 3249 | 4 | Aftertreatment Exhaust Gas Temperature 2 Circuit – Voltage Below Normal or Shorted to Low Source | ||
| SPN 3250 FMI 13 (1691) | 3250 | 13 | Catalyst Efficiency – Out of Calibration | ||
| SPN 3251 FMI 0 (1922) | 3251 | 324 | Aftertreatment Diesel Particulate Filter Differential Pressure – Data Valid But Above Normal Operating Range – Most Severe Level | ||
| SPN 3251 FMI 15 (2639) | 3251 | 15 | 324 | Aftertreatment Diesel Particulate Filter Differential Pressure – Data Valid But Above Normal Operating Range – Least Severe Level | |
| SPN 3251 FMI 16 (1921) | 3251 | 16 | 324 | Aftertreatment Diesel Particulate Filter Differential Pressure – Data Valid But Above Normal Operating Range – Moderately Severe Level | |
| SPN 3251 FMI 2 (1883) | 3251 | 2 | 324 | Aftertreatment Diesel Particulate Filter Differential Pressure Sensor – Data Erratic, Intermittent, or Incorrect | |
| SPN 3251 FMI 3 (1879) | 3251 | 3 | 324 | Aftertreatment Particulate Filter Differential Pressure Sensor Circuit – Voltage Above Normal or Shorted to High Source | |
| SPN 3251 FMI 4 (1881) | 3251 | 4 | 324 | Aftertreatment Particulate Filter Differential Pressure Sensor Circuit – Voltage Below Normal or Shorted to Low Source | |
| SPN 3481 FMI 16 (2778) | 289 | 3481 | 16 | Aftertreatment Fuel Rate – Data Valid But Above Normal Operational Range – Moderately Severe Level | |
| SPN 3489 FMI 18 (3738) | 3489 | 18 | Air Supply Actuator – Data Valid But Below Normal Operating Range – Moderately Severe Level | ||
| SPN 3509 FMI 3 (386) | 3509 | 3 | 212 | Sensor Supply 1 Circuit – Voltage Above Normal or Shorted to High Source | |
| SPN 3509 FMI 4 (352) | 3509 | 4 | 212 | Sensor Supply 1 Circuit – Voltage Below Normal or Shorted to Low Source | |
| SPN 3511 FMI 3 (239) | 3511 | 3 | 232 | Sensor Supply 3 Circuit – Voltage Above Normal or Shorted to High Source | |
| SPN 3511 FMI 4 (238) | 3511 | 4 | 232 | Sensor Supply 3 Circuit – Voltage Below Normal or Shorted to Low Source | |
| SPN 3512 FMI 3 (2185) | 3512 | 3 | 232 | Sensor Supply 4 Circuit – Voltage Above Normal or Shorted to High Source | |
| SPN 3512 FMI 4 (2186) | 3512 | 4 | 232 | Sensor Supply 4 Circuit – Voltage Below Normal or Shorted to Low Source | |
| SPN 3513 FMI 3 (1695) | 3513 | 3 | 232 | Sensor Supply 5 – Voltage Above Normal or Shorted to High Source | |
| SPN 3513 FMI 4 (1696) | 3513 | 4 | 232 | Sensor Supply 5 – Voltage Below Normal or Shorted to Low Source | |
| SPN 3555 FMI 17 (1943) | 3555 | 17 | Ambient Air Density – Data Valid But Below Normal Operational Range – Least Severe Level | ||
| SPN 3556 FMI 16 (2728) | 3556 | 16 | Aftertreatment Fuel Injector 1 – Data Valid But Above Normal Operational Range – Moderately Severe Level | ||
| SPN 3597 FMI 18 (1938) | 3597 | 18 | ECU Power Output Supply Voltage 1 – Data Valid But Below Normal Operational Range – Moderately Severe Level | ||
| SPN 3703 FMI 31 (2777) | 390 | 3703 | 31 | Particulate Trap Active Regeneration Inhibited Due to Permit Switch – Condition Exists | |
| SPN 3936 FMI 15 (1981) | 3936 | 15 | 324 | Aftertreatment Particulate Filter Differential Pressure – Data Valid But Above Normal Operational Range – Least Severe Level | |
| SPN 411 FMI 16 (2359) | 411 | 411 | 16 | Exhaust Gas Recirculation Valve Differential Pressure – Data Valid But Above Normal Operating Range – Moderately Severe Level | |
| SPN 411 FMI 18 (1899) | 411 | 411 | 18 | Exhaust Gas Recirculation Valve Delta Pressure – Data Valid But Below Normal Operating Range – Moderately Severe Level | |
| SPN 411 FMI 2 (1866) | 411 | 411 | 2 | Exhaust Gas Recirculation Valve Delta Pressure – Data Erratic, Intermittent, or Incorrect | |
| SPN 411 FMI 3 (2273) | 411 | 411 | 3 | Exhaust Gas Recirculation Valve Delta Pressure Sensor Circuit – Voltage Above Normal or Shorted to High Source | |
| SPN 411 FMI 4 (2274) | 411 | 411 | 4 | Exhaust Gas Recirculation Valve Delta Pressure Sensor Circuit – Voltage Below Normal or Shorted to Low Source | |
| SPN 412 FMI 15 (2961) | 412 | 412 | 15 | Exhaust Gas Recirculation Temperature – Data Valid But Above Normal Operational Range – Least Severe Level | |
| SPN 412 FMI 16 (2962) | 412 | 412 | 16 | Exhaust Gas Recirculation Temperature – Data Valid But Above Normal Operational Range – Moderately Severe Level | |
| SPN 412 FMI 3 (2375) | 412 | 412 | 3 | Exhaust Gas Recirculation Temperature Sensor Circuit – Voltage Above Normal or Shorted to High Source | |
| SPN 412 FMI 4 (2376) | 412 | 412 | 4 | Exhaust Gas Recirculation Temperature Sensor Circuit – Voltage Below Normal or Shorted to Low Source | |
| SPN 558 FMI 13 (432) | 558 | 13 | 230 | Accelerator Pedal or Lever Idle Validation Circuit – Out of Calibration | |
| SPN 558 FMI 2 (431) | 558 | 2 | 230 | Accelerator Pedal or Lever Idle Validation Circuit – Data Erratic, Intermittent, or Incorrect | |
| SPN 612 FMI 2 (115) | 190 | 612 | 2 | Engine Magnetic Speed / Position Lost Both of Two Signals – Data Erratic, Intermittent, or Incorrect | |
| SPN 627 FMI 12 (351) | 627 | 12 | 251 | Injector Power Supply – Bad Intelligent Device or Component | |
| SPN 627 FMI 2 (1117) | 627 | 2 | 251 | Power Supply Lost With Ignition On – Data Erratic, Intermittent, or Incorrect | |
| SPN 629 FMI 12 (111) | 629 | 12 | 254 | Electronic Control Module Critical Internal Failure – Bad Intelligent Device or Component | |
| SPN 629 FMI 12 (343) | 629 | 12 | 254 | Electronic Control Module Warning Internal Hardware Failure – Bad Intelligent Device or Component | |
| SPN 633 FMI 31 (2311) | 633 | 31 | 18 | Electronic Fuel Injection Control Valve Circuit – Condition Exists | |
| SPN 639 FMI 13 (286) | 639 | 13 | 231 | SAE J1939 Multiplexing Configuration Error – Out of Calibration | |
| SPN 639 FMI 9 (285) | 639 | 9 | 231 | SAE J1939 Multiplexing PGN Timeout Error – Abnormal Update Rate | |
| SPN 639 FMI 9 (427) | 639 | 9 | 231 | SAE J1939 Datalink – Abnormal Update Rate | |
| SPN 641 FMI 11 (2198) | 641 | 11 | 27 | VGT Actuator Driver Circuit – Root Cause Not Known | |
| SPN 641 FMI 12 (2634) | 641 | 12 | 27 | VGT Actuator Controller – Bad Intelligent Device or Component | |
| SPN 641 FMI 13 (2449) | 641 | 13 | 27 | VGT Actuator Controller – Out of Calibration | |
| SPN 641 FMI 15 (1962) | SID 27 | 641 | 15 | VGT Actuator Driver Over Temperature (Calculated) – Data Valid But Above Normal Operational Range – Least Severe Level | |
| SPN 641 FMI 31 (2635) | 641 | 31 | 27 | VGT Actuator Driver Circuit – Condition Exists | |
| SPN 641 FMI 7 (2387) | 641 | 7 | 27 | Variable Geometry Turbocharger (VGT) Actuator Driver Circuit (Motor) – Mechanical System Not Responding Properly or Out of Adjustment | |
| SPN 641 FMI 9 (2636) | 641 | 9 | 27 | VGT Actuator Driver Circuit – Abnormal Update Rate | |
| SPN 647 FMI 3 (2377) | 647 | 3 | 33 | Fan Control Circuit – Voltage Above Normal or Shorted to High Source | |
| SPN 647 FMI 4 (245) | 647 | 4 | 33 | Fan Control Circuit – Voltage Below Normal or Shorted to Low Source | |
| SPN 651 FMI 5 (322) | 651 | 5 | 1 | Injector Solenoid Driver Cylinder 1 Circuit – Current Below Normal or Open Circuit | |
| SPN 652 FMI 5 (331) | 652 | 5 | 2 | Injector Solenoid Driver Cylinder 2 Circuit – Current Below Normal or Open Circuit | |
| SPN 653 FMI 5 (324) | 653 | 5 | 3 | Injector Solenoid Driver Cylinder 3 Circuit – Current Below Normal or Open Circuit | |
| SPN 654 FMI 5 (332) | 654 | 5 | 4 | Injector Solenoid Driver Cylinder 4 Circuit – Current Below Normal or Open Circuit | |
| SPN 655 FMI 5 (323) | 655 | 5 | 5 | Injector Solenoid Driver Cylinder 5 Circuit – Current Below Normal or Open Circuit | |
| SPN 656 FMI 5 (325) | 656 | 5 | 6 | Injector Solenoid Driver Cylinder 6 Circuit – Current Below Normal or Open Circuit | |
| SPN 677 FMI 3 (584) | 677 | 3 | 39 | Starter Relay Driver Circuit – Voltage Above Normal or Shorted to High Source | |
| SPN 677 FMI 4 (585) | 677 | 4 | 39 | Starter Relay Driver Circuit – Voltage Below Normal or Shorted to Low Source | |
| SPN 697 FMI 3 (2557) | 697 | 3 | 57 | Auxiliary PWM Driver 1 – Voltage Above Normal or Shorted to High Source | |
| SPN 697 FMI 4 (2558) | 697 | 4 | 57 | Auxiliary PWM Driver 1 – Voltage Below Normal or Shorted to Low Source | |
| SPN 703 FMI 11 (779) | 703 | 11 | 51 | Auxiliary Equipment Sensor Input 3 – Root Cause Not Known | |
| SPN 703 FMI 14 (2195) | 703 | 14 | 51 | Auxiliary Equipment Sensor Input 3 Engine Protection Critical – Special Instructions | |
| SPN 723 FMI 2 (2322) | 723 | 2 | 64 | Engine Camshaft Speed / Position Sensor – Data Erratic, Intermittent, or Incorrect | |
| SPN 723 FMI 2 (778) | 723 | 2 | 64 | Engine Camshaft Speed / Position – Data Erratic, Intermittent, or Incorrect | |
| SPN 723 FMI 7 (731) | 723 | 7 | 64 | Engine Speed / Position Camshaft and Crankshaft Misalignment – Mechanical System Not Responding Properly or Out of Adjustment | |
| SPN 729 FMI 3 (2555) | 729 | 3 | 70 | Intake Air Heater 1 Circuit – Voltage Above Normal or Shorted to High Source | |
| SPN 729 FMI 4 (2556) | 729 | 4 | 70 | Intake Air Heater 1 Circuit – Voltage Below Normal or Shorted to Low Source | |
| SPN 81 FMI 16 (2754) | 81 | 16 | Engine Particulate Filter Inlet Pressure – Data Valid But Above Normal Operational Range – Moderately Severe Level | ||
| SPN 84 FMI 10 (242) | 84 | 84 | 10 | Wheel-Based Vehicle Speed Sensor Circuit Tampering Has Been Detected – Abnormal Rate of Change | |
| SPN 84 FMI 2 (241) | 84 | 84 | 2 | Wheel-Based Vehicle Speed – Data Erratic, Intermittent, or Incorrect | |
| SPN 91 FMI 19 (287) | 91 | 91 | 19 | SAE J1939 Multiplexed Accelerator Pedal or Lever Sensor System – Received Network Data In Error | |
| SPN 91 FMI 2 (1242) | 91 | 91 | 2 | Accelerator Pedal or Lever Position Sensor 1 and 2 – Data Erratic, Intermittent, or Incorrect | |
| SPN 91 FMI 3 (131) | 91 | 91 | 3 | Accelerator Pedal or Lever Position Sensor 1 Circuit – Voltage Above Normal or Shorted to High Source | |
| SPN 91 FMI 4 (132) | 91 | 91 | 4 | Accelerator Pedal or Lever Position Sensor 1 Circuit – Voltage Below Normal or Shorted to Low Source | |
| SPN 93 FMI 2 (528) | 93 | 93 | 2 | Auxiliary Alternate Torque Validation Switch – Data Erratic, Intermittent, or Incorrect | |
| SPN 974 FMI 19 (288) | 372 | 974 | 19 | SAE J1939 Multiplexing Remote Accelerator Pedal or Lever Position Sensor System – Received Network Data In Error | |
| SPN 974 FMI 3 (133) | 372 | 974 | 3 | Remote Accelerator Pedal or Lever Position Sensor 1 Circuit – Voltage Above Normal or Shorted to High Source | |
| SPN 974 FMI 4 (134) | 372 | 974 | 4 | Remote Accelerator Pedal or Lever Position Sensor 1 Circuit – Voltage Below Normal or Shorted to Low Source | |
| SPN 97 FMI 15 (418) | 97 | 97 | 15 | Water-In-Fuel Indicator – Data Valid But Above Normal Operating Range – Least Severe Level | |
| SPN 97 FMI 3 (428) | 97 | 97 | 3 | Water-in-Fuel Indicator Sensor Circuit – Voltage Above Normal or Shorted to High Source | |
| SPN 97 FMI 4 (429) | 97 | 97 | 4 | Water-in-Fuel Indicator Sensor Circuit – Voltage Below Normal or Shorted to Low Source | |
| SPN 98 FMI 0 (688) | 98 | 98 | Engine Oil Level – Data Valid But Above Normal Operational Range – Most Severe Level | ||
| SPN 98 FMI 1 (253) | 98 | 98 | 1 | Engine Oil Level – Data Valid But Below Normal Operational Range – Most Severe Level | |
| SPN 98 FMI 17 (471) | 98 | 98 | 17 | Engine Oil Level – Data Valid But Below Normal Operational Range – Least Severe Level | |
| SPN 98 FMI 2 (252) | 98 | 98 | 2 | Engine Oil Level – Data Erratic, Intermittent, or Incorrect | |
| SPN 98 FMI 4 (499) | 98 | 98 | 4 | Engine Oil Level Sensor Circuit – Voltage Below Normal or Shorted to Low Source |
For full access to Cummins ISB6.7 (2007-2009) Fault Codes List repair data, wiring diagrams, troubleshooting guides and more, sign up for a free Diesel Repair account today!🔗 Get Started for Free
📱 Now Available: Diesel Repair Mobile App Access fault codes, wiring diagrams, and repair docs right from your phone or tablet—whether you’re in the shop or roadside. The Diesel Repair mobile app is live and ready to keep techs connected on every job.🔗 Download the app or learn more here
